Mersen AJT2 - Amp-Trap 2000 time-delay AJT fuses provide IEC Type "2" (No Damage) protection to main, feeder, and branch-circuits, for all types of loads - yet, they require only half the mounting space needed for 600V UL Class RK fuses. Time-delay characteristics handle motor in-rush currents without nuisance trips. Its current-limiting ability and wide range of ratings provide excellent overcurrent protection for all your applications. An optional mechanical blown fuse indicator and Microswitch is available on blade-type (70 to 600A) fuses for visual and/or remote blown fuse indication. 600 Volts 2 amps .
Mersen

AJT2

Alternate Item Number: AJT2

UPC: 782001963064

Documents & Media
Technical DrawingLine DrawingSpecification Sheet

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Overview

**Mersen Amp-Trap 2000 AJT2 Time-Delay Fuse (SKU: AJT2)** **Key Specifications:** - **Voltage Rating:** 600V AC / 500V DC - **Current Rating:** 2A - **Interrupting Rating:** 300kA (self-certified, UL witnessed) - **Protection Type:** IEC Type 2 (No Damage) for 600V, 2A circuits - **Mounting Space:** 50% reduction vs. UL Class RK fuses - **Compliance:** UL 248-8, CSA C22.2 No. 248.8, IEC 60269-2-1 **Features & Benefits:** - **Time-delay design** for motor in-rush current handling without nuisance trips. - **Current-limiting** to reduce fault energy, arc flash hazards, and equipment damage. - **Blade-type versions (70–600A)** with optional **SmartSpot visual indicators** and **Microswitches** for remote monitoring. - **UL-listed** and **CSA-certified** for global reliability. **Applications:** - **Motor control centers (MCCs)** and **VFDs** (common in manufacturing, food processing, automotive). - **Industrial machinery** with high in-rush currents. - **Commercial buildings** (data centers, hospitals). - **Renewable energy systems** (solar inverters, wind turbines). - **Critical infrastructure** (water treatment, telecom). **Installation & Selection:** - Verify **voltage (600V AC/500V DC)**, **current (2A)**, and **mounting compatibility**. - Time-delay curve optimized for inductive loads; consult Mersen’s application guides for motor/transformer protection. - **Microswitch option** integrates with SCADA/PLC for remote fault monitoring. **Why Choose AJT2?** - **IEC Type 2 compliance** prevents downstream equipment damage. - **Space-saving design** reduces panel footprint and installation costs. - **Compatible with UL Class RK holders** for easy upgrades. - **Optional monitoring** (SmartSpot/Microswitch) for predictive maintenance. **Industry Standards:** - **UL 248-8**, **CSA C22.2 No. 248.8**, **IEC 60269-2-1** - **Global manufacturing** with consistent quality and technical support. **Best for:** New installations or retrofits requiring **reliable, space-efficient, future-proof** overcurrent protection.
  • IEC Type 2 (No Damage) protection for 600V, 2A circuits
  • 300kA interrupting rating (self-certified, UL witnessed)
  • Time-delay characteristics for motor in-rush currents
  • Half the mounting space of 600V UL Class RK fuses
  • Optional SmartSpot visual blown fuse indicator (70–600A)
  • UL-listed (UL 248-8), CSA-certified, and IEC 60269-2-1 compliant
  • Current-limiting design reduces arc flash hazards
  • Compatible with UL Class RK fuse holders

Specifications

AC Voltage Rating
600 V
Amperage Rating
2 A
Application
Motor circuits Mains Feeders Branch circuits Lighting, heating & general loads Transformers Control panels Circuit breaker back-up Bus duct Load centers
Application
Motor Circuits Mains Feeders Branch Circuits Lighting Heaters Transformers Control Panels Circuit Breaker Back-up Bus Duct Load Centers
Body Material
GMG
Brand Name
Ferraz Shawmut
Class
Class J
Connection
Ferrule
Connection Material
Tin-Plated Copper
Connection Type
Blade-type
Current Rating
2 A
Interrupt Rating
200 kA
Material
Fiberglass, Silica
Mounting
Clip
Mounting Type
Fuse Block
Series
Amp-Trap 2000 AJT
Series
Amp-Trap 2000
Size
Class J dimensions
Size
2.25 x 0.81 in
Size
57.15 x 20.65 mm
Special Features
Non-indicating or solid state SmartSpot visual blown fuse indicator Time-delay for motor starting and transformer inrush Self Certified 700VAC, 15-600A range, 100kA IR 300kA interrupting rating - self-certified, UL witnessed tests Extremely current-limiting for low peak let-thru current Most current-limiting UL class fuse Recommended for Arc Flash energy reduction Small footprint requires less mounting space and allows smaller, more economical fuse blocks Easy 2-to-1 selectivity for prevention of nuisance shutdowns Unique Class J dimensions prevent replacement errors High-visibility orange label gives instant brand recognition Metal-embossed date and catalog number for traceability and lasting identification Fiberglass body provides dimensional stability in harsh industrial settings High-grade silica filler ensures fast arc quenching Optional EI indicator/switch mount for AJT70 to 600 open fuse indication
Special Features
Solid-state SmartSpot indicator Time-delay for motor starting and transformer inrush 300kA interrupting rating, self-certified (UL witnessed) Extremely current-limiting for low peak let-thru current Most current-limiting UL class fuse Small footprint requires less mounting space and allows smaller, more economical fuse blocks Easy 2-to-1 selectivity for prevention of nuisance shutdowns Unique Class J dimensions prevent replacement errors High-visibility orange label gives instant recognition Metal embossed date and catalog number for traceability and lasting identification Fiberglass body provides dimensional stability in harsh industrial settings High-grade silica filler ensures fast arc quenching Optional EI blown fuse indicator/switch available
Standard
UL Listed to Standard 248-8, File E2137 DC Listed to UL Standard 248 CSA Certified to Standard C22.2, No. 248.8 IEC 269-2-1
Standard
AJT (1-600): UL listed to standard 248-8 File E2137 DC listed to UL standard 248 CSA certified to standard C22.2 No. 248.8 IEC 60269-2-1 AJT (70-600) EI: UL listed DC tested to UL standard 248 Self Certified 700VAC, 15-600A range
Sub Brand
Amp-Trap® 2000, SmartSpot®
Type
Class J
Type
North American Power Fuses
Voltage Rating
600 VAC
Package Dimensions (L x W x H)
2.25 IN x 0.813 IN x 0.813 IN
Package Dimensions (L x W x H)
5.715 cm x 20.6502 mm x 20.6502 mm
Package Weight (Imperial)
0.200 L
Package Weight (Metric)
0.091 kg
