Mersen AF2-5 - Blade Style Automotive Fuse 32 Volts 5 amps AF2 series.
Mersen

AF2-5

Alternate Item Number: 782001244194

UPC: 782001244194

Contact for Pricing

Minimum Qty: 5

Multiplier: 5

*Contact for lower quantities*

Overview

The Mersen AF2-5 Blade Style Automotive Fuse (SKU: AF2-5) is a precision-engineered circuit protection solution designed for 32V electrical systems requiring a 5-amp current rating. Part of Mersen’s trusted AF2 series, this blade-style fuse delivers reliable performance in automotive, marine, recreational vehicle, and industrial applications where robust overcurrent protection is critical. Engineered to meet the demands of high-vibration environments, the AF2-5 fuse combines durability with fast-acting response to prevent damage from short circuits, overloads, and transient surges. Its compact, blade-style design ensures easy installation in fuse blocks, panels, and distribution systems, making it a preferred choice among technicians and engineers. The 32V rating makes it suitable for 12V and 24V systems with transient voltage spikes, while the 5A current rating provides precise protection for sensitive circuits such as lighting, sensors, control modules, and auxiliary systems. The blade-style construction, featuring a flat, tabbed terminal, ensures secure contact and low contact resistance, reducing the risk of overheating or intermittent failures. This design also facilitates quick replacement during troubleshooting, minimizing downtime in critical applications.
  • 5A current rating for precise circuit protection
  • 32V voltage rating suitable for 12V/24V systems with transient spikes
  • Blade-style design with zinc alloy terminals for secure contact
  • Fast-acting response to prevent short circuits and overloads
  • Compact size for high-density packaging in fuse panels

Specifications

Amperage Rating
5 A
Application
Automobiles, trucks and other low voltage applications.
Brand Name
Ferraz Shawmut
Connection
Blade
Current Rating
5A
Interrupt Rating
1 kA
Mounting
Clip
Series
AF2
Special Features
Fast-Acting
Standard
RoHS Compliant
Type
Automotive Fuse
Type Of Indicators
Clear Body
Voltage Rating
32 VAC
Voltage Rating
32V VAC
Package Dimensions (L x W x H)
0.68 IN x 0.43 IN x 0.1 IN
Package Dimensions (L x W x H)
17.272 mm x 10.922 mm x 2.54 mm
Package Weight (Imperial)
0.002 L
Package Weight (Metric)
0.001 kg
