Mersen A70QS10-22F - These Premium Amp-trap French Cylindrical Semiconductor Fuses are an extension of the popular A70QS product line. They are solid-fill 14mm and 22mm fuses IEC rated 690VAC, 200kA Interrupting and 700VDC, 100kA interrupting at 10ms time constant. In addition, these fuses have an 890 VDC rating for capacitor discharge applications up to 2.5ms time constant. All ampere ratings are available with a striker. Applications include small inverter drives and UPS systems, with superior I²t for improved protection and performance. 690 Volts 10 amps 22x58 ferrule.
Mersen

A70QS10-22F

Alternate Item Number: 782001358839

UPC: 782001358839

Contact for Pricing

Overview

The Mersen A70QS10-22F Premium Amp-trap French Cylindrical Semiconductor Fuse represents a significant advancement in overcurrent protection for critical industrial applications. As an integral part of the highly regarded A70QS product line, this fuse is engineered to deliver exceptional performance and reliability where system uptime and component integrity are paramount. This specific model, the A70QS10-22F, is a 10 Ampere fuse featuring a standard 22x58mm ferrule size, designed to meet stringent IEC rating standards. Engineered for demanding environments, the A70QS10-22F boasts impressive interrupting ratings, crucial for safeguarding sensitive semiconductor devices. It is rated for 690 Volts AC with an exceptional 200kA interrupting capacity, providing robust protection against severe short-circuit events. Furthermore, it extends its protective capabilities to DC circuits, rated at 700 Volts DC with a 100kA interrupting capacity at a 10ms time constant. This dual AC/DC capability makes it a versatile choice for a wide array of power electronics systems. A standout feature of this premium fuse is its specialized 890 VDC rating, specifically tailored for capacitor discharge applications. This rating allows for effective protection during the rapid energy release characteristic of capacitor banks, with a time constant as short as 2.5ms. This capability is vital for applications involving pulsed power systems, high-frequency converters, and other scenarios where rapid discharge protection is essential. The A70QS10-22F utilizes a solid-fill construction, a hallmark of Mersen's premium fuse technology, which enhances its thermal management and overall durability. This construction method contributes to superior I²t performance, meaning it offers improved energy limitation during fault conditions. Lower I²t values translate to less energy being passed through the protected circuit during a fault, thereby minimizing damage to sensitive components like diodes, SCRs, and IGBTs. This enhanced protection directly contributes to improved system performance and extended equipment lifespan. Key applications for the Mersen A70QS10-22F include: * Small inverter drives and variable frequency drives (VFDs) * Uninterruptible Power Supply (UPS) systems * DC power supplies * Motor control centers * Renewable energy systems (e.g., solar inverters) * Industrial automation equipment * Capacitor banks for power factor correction and energy storage With all ampere ratings available with an optional striker mechanism, the A70QS10-22F can be integrated into fuse monitoring systems, providing immediate visual or electrical indication of a blown fuse. This feature is critical for rapid troubleshooting and maintenance in complex industrial setups. Mersen's commitment to quality and innovation is evident in the A70QS series, offering engineers and maintenance professionals a trusted solution for safeguarding their valuable equipment. Choosing the Mersen A70QS10-22F ensures a high level of protection, reliability, and performance for your most critical power electronic applications.
  • Premium Amp-trap French Cylindrical Semiconductor Fuse (SKU: A70QS10-22F)
  • 10A, 22x58mm ferrule size
  • IEC Rated: 690VAC, 200kA interrupting; 700VDC, 100kA interrupting (10ms)
  • Specialized 890VDC rating for capacitor discharge (up to 2.5ms)
  • Superior I²t for enhanced semiconductor protection in inverter drives and UPS systems

Specifications

Amperage Rating
10 A
Application
Small inverters, UPS systems, Solid State Relays, motor drives and similar 700V or less equipment
Brand Name
Ferraz Shawmut
Connection
Ferrule
Mounting
Clip
Special Features
International 14 x 51mm (2 In x 9/16 In) and 22 x 58mm (2-1/4 In x 13/16 In) sizes for worldwide acceptance Ferrule mount for design versatility Very low I2t for improved semiconductor protection 690V IEC rated, tested at 760VAC, can be used up to 750VAC in U.S. 700VDC rated for dc protection of equipment with L/R <= 10ms/c Superior cycling ability for longer life on difficult cyclic loading applications
Standard
UL Recognized Component CSA Certified IEC 269-4 Compliance
Type
North American Round Style
Voltage Rating
690 VAC
Package Dimensions (L x W x H)
2.28 IN x 0.86 IN x 0.86 IN
Package Dimensions (L x W x H)
5.7912 cm x 21.844 mm x 21.844 mm
Package Weight (Imperial)
0.100 L
Package Weight (Metric)
0.045 kg
