Contact for Pricing
Overview
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 500 A |
Application | Protection of heavy traction and electrochemical as well as rectifiers and other heavy-duty equipment |
Brand Name | Mersen |
Case | GMG |
Connection | Blade |
Mounting | Bolted |
Size | 5.13 x 2 in |
Size | 130.302 x 50.8 mm |
Special Features | Low I2t minimizes damage to protected components on short circuit Controlled arc voltage reduces stress to circuit components during fuse clearing Choice of mounting types helps in equipment design |
Standard | UL recognized component UL file E60314 AC: UL guide no. JFHR2 (35-800A) |
Sub Brand | Amp-Trap® |
Type | Round Body High-Speed Fuse-Links AC Protection |
Voltage Rating | 600 V |
Package Dimensions (L x W x H) | 5.13 in x 2 in x 2 in |
Package Dimensions (L x W x H) | 130.302 mm x 50.8 mm x 50.8 mm |
Package Weight (Imperial) | 1.400 lb |
Package Weight (Metric) | 0.635 kg |
