Mersen A30QS150-4L - A30QS Amp-trap Semiconductor Protection fuses are intended for the protection of Power Semiconductors such as Diodes, Phase Control SCR's and other power Semiconductor devices. The A30QS is recommended for new applications providing solutions for your critical protection needs at 300V and less semiconductors 300 Volts 150 Amps type 4L connection.
Mersen

A30QS150-4L

Alternate Item Number: 782001141172

UPC: 782001141172

Documents & Media
Specification Sheet

Contact for Pricing

Overview

The Mersen A30QS150-4L Amp-trap Semiconductor Protection Fuse is a critical component engineered for the robust safeguarding of sensitive power semiconductor devices. This high-performance fuse is specifically designed to protect critical components such as diodes, phase control SCRs (Silicon Controlled Rectifiers), and other advanced power semiconductor technologies. It provides essential overcurrent protection, ensuring the integrity and longevity of these vital electronic elements in demanding industrial and power electronics applications. Engineered for reliability and precision, the A30QS series, including the A30QS150-4L, is the recommended choice for new applications requiring dependable protection for semiconductors operating at voltages of 300V and below. This fuse offers a superior solution for mitigating the risks associated with short circuits and other electrical faults that could otherwise lead to catastrophic damage to expensive semiconductor equipment. Its design prioritizes fast-acting interruption, minimizing the duration of fault currents and thereby reducing thermal stress on protected devices. Key specifications of the Mersen A30QS150-4L include a voltage rating of 300 Volts and a substantial current rating of 150 Amps. The '4L' designation signifies a specific connection type, crucial for ensuring proper integration within existing electrical systems and equipment designs. This fuse is built to meet stringent industry standards, offering peace of mind to engineers and maintenance professionals who rely on Mersen's established reputation for quality and innovation in electrical protection. Applications for the A30QS150-4L are widespread across various sectors, including: * **Industrial Power Supplies:** Protecting rectifiers and inverters in heavy-duty machinery and manufacturing equipment. * **Renewable Energy Systems:** Safeguarding power conversion components in solar inverters and wind turbine converters. * **Motor Drives:** Ensuring the protection of SCRs and diodes in variable speed drives for precise motor control. * **Uninterruptible Power Supplies (UPS):** Providing reliable protection for semiconductor components in critical backup power systems. * **Electric Vehicle Charging Infrastructure:** Protecting power electronics in high-capacity charging stations. When selecting semiconductor protection fuses, factors such as voltage rating, current rating, interrupting capacity, and connection type are paramount. The Mersen A30QS150-4L addresses these needs with its specific 300V, 150A rating and 4L connection, making it a direct and effective solution for many system designs. Mersen's commitment to advanced fuse technology ensures that users receive products that not only meet but often exceed the demanding requirements of modern power electronics. By choosing the A30QS150-4L, you are investing in the stability, safety, and operational continuity of your critical semiconductor-based systems, backed by the expertise of a global leader in electrical protection.
  • Designed for protection of Power Semiconductors (Diodes, SCRs, etc.)
  • Recommended for new applications at 300V and less
  • Voltage Rating: 300 Volts
  • Current Rating: 150 Amps
  • Connection Type: 4L

Specifications

Amperage Rating
150 A
Application
Protection of AC/DC drives, UPS and other equipment of 300 volts or less
Brand Name
Ferraz Shawmut
Connection
Blade
Connection Type
4L
Current Rating
150 A
Mounting
Bolted
Series
A30QS
Special Features
300VAC and 300VDC rated Low I 2 t minimizes damage to protected component on short circuit. Controlled arc Voltage reduces stress to circuit components during fuse clearing. Choice of mounting types helps in equipment design
Standard
UL Recognized Component Guide JFHR2 Some Ratings RoHS Compliant
Type
North American Round Style
Voltage Rating
300 VAC
Package Dimensions (L x W x H)
2.2 IN x 0.92 IN x 0.92 IN
Package Dimensions (L x W x H)
5.588 cm x 23.368 mm x 23.368 mm
Package Weight (Imperial)
0.180 L
Package Weight (Metric)
0.082 kg
