Contact for Pricing
Minimum Qty: 10
Multiplier: 10
*Contact for lower quantities*
Overview
- Class RK1 Time-Delay Fuse (A2D-R series)
- 4.5 Ampere Rating
- 250V AC / 250V DC Voltage Rating
- 200kA AC / 100kA DC Interrupting Rating
- Provides IEC Type 2 "no damage" protection
Specifications
AC Voltage Rating | 250 V |
Amperage Rating | 4.5 A |
Application | Motors Safety switches Transformers Branch circuit protection Disconnects Control panels All general-purpose circuits |
Body Material | PolyTube |
Brand Name | Mersen |
Class | Class RK1 |
Connection | Ferrule |
Connection Material | Tin-Plated Copper |
Connection Type | Ferrule |
Current Rating | 4.5A |
Interrupt Rating | 200 kA |
Mounting | Clip |
Nema Rating | Class RK1 |
Series | Amp-Trap 2000 |
Size | 2 x 0.56 in |
Size | 50.8 x 14.224 mm |
Size | 2 x 0.56;50.8 x 14.224 in;mm |
Special Features | Non-indicating or Solid state SmartSpot visual blown fuse indicator Time-delay for motor starting and transformer inrush currents without nuisance opening 600VAC & 600VDC dual rated 300kA interrupting rating - self-certified, UL witnessed tests Extremely current-limiting for low peak let-thru current Recommended for Arc Flash energy reduction Easy 2-to-1 selectivity for prevention of nuisance shut downs and “black outs” Rejection-style design prevents replacement errors (when used with recommended fuse blocks) High-visibility orange label gives instant brand recognition Reduced inventory by taking the place of class RK5, K, and H fuses Metal-embossed date and catalog number for easier traceability and lasting identification Fiberglass body provides dimensional stability in harsh industrial settings |
Standard | UL listed to standard 248-12 File E2137 DC listed to UL standard 248 CSA certified to standard C22.2 No. 248.12 |
Sub Brand | Amp-Trap 2000® |
Type | Class RK1 |
Voltage Rating | 250 VAC |
Voltage Rating | 250VAC 250VDC |
Package Dimensions (L x W x H) | 2 in x 0.56 in x 0.56 in |
Package Dimensions (L x W x H) | 50.8 mm x 14.224 mm x 14.224 mm |
Package Weight (Imperial) | 0.037 lb |
Package Weight (Metric) | 0.017 kg |
