Mersen A13X400-4 - A13X Amp-trap Form 101 Semiconductor Protection fuses were designed for the specific protection of diodes and other semiconductor devices rated 130VAC. The A13X product line's compact design is perfect for those applications that have limitations on available space. 130 Volts 400 Amps type 4 connection.
Mersen

A13X400-4

Alternate Item Number: 782001941406

UPC: 782001941406

Contact for Pricing

Overview

The Mersen A13X400-4 Amp-trap Form 101 Semiconductor Protection Fuse is a critical component engineered for the precise and reliable protection of sensitive semiconductor devices, including diodes, SCRs, and other power electronics. Designed specifically for applications operating at 130VAC, this fuse offers robust safeguarding against overcurrents and short circuits that could otherwise lead to catastrophic equipment failure. The A13X product line is distinguished by its compact design, making it an ideal solution for applications where space is a significant constraint. This allows for integration into densely packed control panels, power supplies, and industrial machinery without compromising on protection capabilities. The A13X400-4 model features a substantial 400 Amp current rating, suitable for high-power semiconductor applications, and a Type 4 connection, ensuring secure and efficient integration into electrical systems. Key features and benefits of the Mersen A13X400-4 include: * **Specialized Semiconductor Protection:** Tailored to the unique protection needs of diodes and other semiconductor devices, offering fast-acting response to fault conditions. * **Compact Form Factor:** Optimized for space-constrained environments, facilitating easier installation and panel design. * **High Current Rating:** A 400A rating supports demanding industrial power applications. * **130VAC Voltage Rating:** Specifically designed for systems operating at this voltage level, ensuring optimal performance and safety. * **Type 4 Connection:** Provides a reliable and secure electrical connection. * **Mersen Quality and Reliability:** Backed by Mersen's extensive experience and reputation in electrical protection solutions, ensuring dependable performance and longevity. Semiconductor devices are the backbone of modern power electronics, enabling efficient conversion and control of electrical energy. However, their sensitivity to transient overcurrents and fault conditions necessitates specialized protection. Standard fuses may not offer the fast-acting response or specific current-limiting characteristics required to protect these delicate components. The Mersen Amp-trap Form 101 series, including the A13X400-4, addresses this need by providing a fuse with a low I²t value and a rapid clearing time, effectively absorbing fault energy and preventing damage to the protected semiconductor. Applications for the Mersen A13X400-4 are widespread across various industrial sectors. These include: * **Variable Frequency Drives (VFDs):** Protecting the power modules within VFDs used for motor speed control. * **Uninterruptible Power Supplies (UPS):** Safeguarding the power semiconductor components in battery backup systems. * **Power Supplies:** Protecting diodes and transistors in industrial power conversion equipment. * **Motor Controllers:** Ensuring the integrity of semiconductor devices in motor starting and control circuits. * **Renewable Energy Systems:** Protecting inverters and converters in solar and wind power installations. When selecting semiconductor protection fuses, engineers consider factors such as the rated voltage, continuous current, interrupting rating, and the specific characteristics of the semiconductor device being protected. The Mersen A13X400-4, with its 130VAC rating and 400A capacity, is a meticulously designed solution that meets these critical requirements. Mersen's commitment to innovation and quality ensures that their Amp-trap fuses provide the highest level of protection, contributing to the operational reliability and safety of complex electrical systems. Trust Mersen to deliver superior semiconductor protection for your most critical applications.
  • Mersen A13X400-4 Amp-trap Form 101 Semiconductor Protection Fuse
  • Designed for 130VAC semiconductor device protection (diodes, SCRs)
  • Compact design ideal for space-constrained applications
  • 400 Amp current rating for high-power industrial use
  • Type 4 connection for secure electrical integration

Specifications

Amperage Rating
400 A
Application
Protection of drives, UPS, Rectifiers and other equipment of 130 volts or less
Brand Name
Ferraz Shawmut
Connection
Blade
Connection Type
Type 4
Current Rating
400 A
Mounting
Bolted
Nema Rating
Type 4
Series
A13X Amp-trap Form 101
Standard
UL Recognized Component Guide JFHR8, File E60314 Some Ratings RoHS Compliant
Type
North American Round Style
Voltage Rating
130 VAC
Package Dimensions (L x W x H)
2.66 IN x 1.13 IN x 1.13 IN
Package Dimensions (L x W x H)
6.7564 cm x 2.8702 cm x 2.8702 cm
Package Weight (Imperial)
0.250 L
Package Weight (Metric)
0.113 kg
