Mencom Corporation E45V3-8FFR-M25 - Ethernet, E45V3 Receptacle, 8 Pole, Female Straight / Female Straight, M25, Front Mount, Plastic, UL508A, UL50, UL50E

Mencom Corporation E45V3-8FFR-M25 Ethernet, E45V3 Receptacle, 8 Pole, Female Straight / Female Straight, M25, Front Mount…

Documents & Media
BrochureTechnical DrawingLine DrawingManufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The Mencom Corporation E45V3-8FFR-M25 is a robust 8-conductor Ethernet receptacle engineered for dependable data connectivity within demanding industrial environments. This specific model, the E45V3-8FFR-M25, is designed for front mounting applications and features an M25 thread size, facilitating secure installation. Its configuration is female straight to female straight, ensuring compatibility with standard RJ45 patch cords for seamless integration into existing networks. Constructed from durable plastic, the E45V3-8FFR-M25 adheres to stringent safety standards, holding certifications for UL508A, UL50, and UL50E. These certifications underscore its suitability for use in industrial control equipment and enclosures. The E45V3 series receptacles, including this M25 variant, are rated for 42 VDC and 1.5 amps, providing sufficient power and current handling for typical industrial Ethernet applications. When properly sealed, these receptacles achieve an IP65 ingress protection rating, safeguarding against dust and water jets. Detailed specifications for the E45V3-8FFR-M25 include a polyamide insulator, which offers excellent dielectric strength and mechanical stability. The unit is equipped with an NBR O-ring for effective sealing and features copper alloy contacts that are gold-plated to ensure superior conductivity and corrosion resistance, critical for maintaining signal integrity in harsh conditions. The maximum panel thickness that can be accommodated by this front-mount receptacle is 5.5 mm. For optimal and secure installation, a recommended tightening torque of 5.0 N-m should be applied. The operational resilience of the E45V3-8FFR-M25 is further demonstrated by its wide operating temperature range, spanning from -20ºC to +80ºC (-4ºF to +176ºF), making it suitable for deployment in a variety of climatic conditions. This receptacle is an integral part of Mencom's Etherlink V3 series, a line of products designed to deliver robust and reliable connections for industrial Ethernet applications. The E45V3-8FFR-M25 is classified under UNSPSC code 39121406.
  • 8-conductor Ethernet receptacle with female straight to female straight connections
  • M25 front mount design with a maximum panel thickness of 5.5 mm
  • Durable plastic construction meeting UL508A, UL50, and UL50E safety standards
  • IP65 ingress protection rating for dust and water resistance
  • Rated for 42 VDC, 1.5 amps with a temperature range of -20ºC to +80ºC

Specifications

Connection Type
Female Straight / Female Straight
Connection Type
Female Straight to Female Straight
Material
Plastic
Mounting Type
Front Mount
Poles
8
Series
E45V3
Size
M25
Wall Plate Standard 1 Gang Blank WH

600WH-25

Wall Plate Standard 1 Gang Blank WH
600T Modified for Switchboard Users

600T-MOD

600T Modified for Switchboard Users
One-Gang Nail-On New Work Outlet Box, Volume 18 Cubic Inches, Length 3-3/4 Inches, Width 2-1/4 Inches, Depth 2-7/8 Inches, Color Blue, Material PVC, Mounting Means Captive Nails

B118A

One-Gang Nail-On New Work Outlet Box, Volume 18 Cubic Inches, Length 3-3/4 Inches, Width 2-1/4 Inches, Depth 2-7/8 Inches, Color Blue, Material PVC, Mounting Means Captive Nails
One-Gang Box Cover, Volume 8.1 Cubic Inches, 4 Inches Square, Raised 1-1/4 Inch, Color Blue, Material Non-Metallic

A414

One-Gang Box Cover, Volume 8.1 Cubic Inches, 4 Inches Square, Raised 1-1/4 Inch, Color Blue, Material Non-Metallic
One-Gang Low-Voltage Adjustable Bracket, Color Orange, Material Non-Metallic

SC100ADJC

One-Gang Low-Voltage Adjustable Bracket, Color Orange, Material Non-Metallic
One-Gang Low-Voltage Old Work Bracket, Length 4.32 Inches, Width 2.52 Inches, Depth 1.66 Inches, Color Orange, Material Non-Metallic

SC100RR

One-Gang Low-Voltage Old Work Bracket, Length 4.32 Inches, Width 2.52 Inches, Depth 1.66 Inches, Color Orange, Material Non-Metallic
One-Gang Box Cover, Volume 3.5 Cubic Inches, 4 Inches Square, Raised 1/2 Inch, Color Blue, Material Non-Metallic

A410R-CAR

One-Gang Box Cover, Volume 3.5 Cubic Inches, 4 Inches Square, Raised 1/2 Inch, Color Blue, Material Non-Metallic
Two-Gang Nail-On New Work Outlet Box, Volume 32 Cubic Inches, Length 3-3/4 Inches, Width 4 Inches, Depth 3 Inches, Color Blue, Material PVC, Mounting Means Captive Nails

B232ACP

Two-Gang Nail-On New Work Outlet Box, Volume 32 Cubic Inches, Length 3-3/4 Inches, Width 4 Inches, Depth 3 Inches, Color Blue, Material PVC, Mounting Means Captive Nails
The Polaris IPLMD350-6 Multi-Tap Mountable Dual-Sided Entry Connector features 6 ports sized for 350 MCM - 6 AWG wires. Mounting holes on either side of the connector allow for direct mounting to troughs, panels or wireways with 1/4†bolts. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.

IPLMD350-6

The Polaris IPLMD350-6 Multi-Tap Mountable Dual-Sided Entry Connector features 6 ports sized for 350 MCM - 6 AWG wires. Mounting holes on either side of the connector allow for direct mounting to troughs, panels or wireways with 1/4†bolts. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.
Heat Shrink Ring Terminal 12 10 AWG, 3/8" stud size.

PH10-38R-E

Heat Shrink Ring Terminal 12 10 AWG, 3/8" stud size.
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black

LH38

Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
EP-RJG-M20-BL-A

1SNG618003R0000

EP-RJG-M20-BL-A

Frequently Asked Questions

What is the operating temperature range for the E45V3-8FFR-M25?

The operating temperature range is -20ºC to +80ºC (-4ºF to +176ºF).

What material are the contacts made of and what plating do they have?

The contacts are made of Copper Alloy with Gold Plating.

What are the electrical ratings for the Female Front Mount Receptacles?

The Female Front Mount Receptacles are rated for 42 VDC and 1.5 amps.

What is the IP rating of the Female Front Mount Receptacles?

The Female Front Mount Receptacles have an IP65 rating.

What is the maximum panel thickness for this receptacle?

The maximum panel thickness for this receptacle is 5.5 mm.

What is the insulator material for the Etherlink V3 series?

The insulator material for the Etherlink V3 series is Polyamide.

What is the O-Ring material used in this product?

The O-Ring material used in this product is NBR.

What is the tightening torque specification for this product?

The specified tightening torque for this product is 5.0 N-m.

What thread size is used for the receptacle mounting?

The receptacle uses a 1”-14UNC thread for mounting.

What type of cable is used with the Etherlink V3 series?

The Etherlink V3 series uses CAT5e cable with a PVC Jacket.
