Overview
- Multi-function: Overcurrent, Undercurrent, Band (Window) monitoring
- Selectable latching option for fault state retention
- Adjustable MAX and MIN dials for precise trip threshold setting
- 0.1A - 10A adjustable current range
- 100ms pick-up and drop-out response time
- Compact plug-in design with standard 8 or 11-pin octal sockets
- UL Component Recognized and UL Listed (with appropriate socket)
How to Install the CMD10AD2U Current Sensing Relay
This guide provides step-by-step instructions for installing and configuring the CMD10AD2U Current Sensing Relay on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the relay
Secure the CMD10AD2U relay to the DIN rail using the integrated clips. Ensure the relay is level and firmly attached.
- Connect the power supply
Using terminal connectors, connect the power supply to the relay's input terminals. Ensure the voltage is within the specified range of 24-240V AC/DC.
- Wire the load
Connect the load to the relay's output terminals. Verify that the load does not exceed the relay's maximum allowable current rating.
- Configure the settings
Adjust the MAX and MIN threshold dials on the relay to set the desired current limits. Set the tripping delay and start-up sensing delay as needed.
- Test the installation
Power on the system and use a multimeter to verify that the relay is functioning correctly. Check the LED indicators for proper operation.
