Overview
- 120V AC input voltage with 2-180s adjustable delay range
- 10A DPDT output contacts with ±2% repeat accuracy
- ±10% factory calibration tolerance for precise timing
- Fast reset (<100ms) and input-to-output isolation
- Standard plug-in base wiring for easy OEM integration
Specifications
Connection Type | Plug-in base wiring |
Current Rating | 10 A |
Frequency | 50/60Hz |
Material | Electronic/Digital |
Poles | DPDT |
Series | TRM |
Voltage Rating | 120 VAC |

1-1393143-3
Relay Accessories, Sockets & Clips, Printed Circuit Board, Phenolic, Printed Circuit Board, 6, Socket, Potter & Brumfield R10
1-1393143-6
Relay Accessories, Sockets & Clips, Solder, Polyester, Printed Circuit Board, 2, Socket, Potter & Brumfield R10
SCP102D24X-C02
IP67 SCP-X Extreme Environment Series Power Supply. Double Stacked, Output Power 2 x 100W, Output Voltage 24 Vdc, Output Current 7.6 A total, 3.8 A per pairFrequently Asked Questions
What is the TRM series time delay relay type?
The TRM series is a digital electronic circuitry time delay relay with an electromechanical relay output.
How does the TRM series operate in a delay-on-make configuration?
Upon input voltage application, the time delay begins. The output energizes at the end of the delay and remains energized until input voltage is removed.
What is the repeat accuracy of the TRM series relays?
The TRM series offers a repeat accuracy of +/- 2%.
What are the output contact specifications for the TRM series?
The TRM series has isolated 8 A, SPDT or DPDT output contacts.
What input voltages are available for the TRM series?
Available input voltages include 24 V dc, 24 V ac, and 120 V ac.
What is the output rating for the TRM series relays?
The output rating is 8 A resistive @ 120/240 V ac and 1/3 hp @ 120/240 V ac.
What is the isolation voltage provided by the TRM series?
The TRM series provides an isolation voltage of greater than or equal to 1500 V rms between input and output terminals.
Are the DC units in the TRM series reverse polarity protected?
Yes, DC units in the TRM series are reverse polarity protected.
What is the operating temperature range for the TRM series?
The operating temperature range for the TRM series is -20 °C to 65 °C.
What is the voltage tolerance for the 24V DC/AC input on TRM series?
The voltage tolerance for 24 V dc/ac input is -15% to 20%.
