Littelfuse SPF015HXR - The SPF Solar Protection Fuse series has been specifically designed for the protection of photovoltaic (PV) systems. This family of Midget style fuses (10 x 38 mm) can safely protect PV modules and conductors from reverseovercurrent conditions. As PV systems have grown in size, so have the corresponding voltage requirements. This increase in system voltage has typically been intended to minimize power loss associated with long conductor runs. Standard circuit protection devices are not designed to completely protect photovoltaic panels. However, the SPF series is UL Listed to safely interrupt faulted circuits up to this demanding voltage level. Littelfuse offers multiple ampere ratings to match specific requirements in a variety of applications.
Littelfuse

SPF015HXR

Alternate Item Number: 0SPF015.HXR

UPC: 079458169362

Documents & Media
BrochureTechnical BulletinTechnical DrawingSpecification SheetVideo Clip

Contact for Pricing

Minimum Qty: 100

Multiplier: 100

*Contact for lower quantities*

Overview

The Littelfuse SPF015HXR Solar Protection Fuse (SKU: SPF015HXR) is a critical component engineered for the robust protection of photovoltaic (PV) systems. As solar energy installations continue to expand in scale and complexity, the demand for specialized circuit protection that can withstand higher system voltages and mitigate reverse overcurrent conditions becomes paramount. Standard circuit protection devices are often insufficient for the unique challenges presented by PV arrays, which can experience significant power losses due to long conductor runs and require protection against fault currents originating from multiple modules. The SPF series, including the SPF015HXR, addresses these challenges directly. These Midget-style fuses, measuring 10 x 38 mm, are specifically designed to safeguard PV modules and associated conductors from potentially damaging reverse overcurrents. This capability is essential for maintaining the integrity and longevity of solar installations. The increasing voltage requirements in modern PV systems, aimed at optimizing efficiency by minimizing resistive losses, necessitate protection devices rated for these demanding levels. The SPF015HXR is UL Listed, providing assurance that it can safely interrupt faulted circuits up to these elevated voltages, a critical safety and performance benchmark for solar applications. Littelfuse, a globally recognized leader in circuit protection, offers the SPF series with multiple ampere ratings. This allows for precise matching of protection to the specific requirements of diverse PV system designs, from residential rooftops to large-scale commercial and industrial solar farms. Proper fuse selection is crucial for ensuring that the protection scheme is both effective against faults and minimizes nuisance tripping during normal operation. The SPF015HXR's design ensures reliable performance, contributing to enhanced system safety, reduced downtime, and optimized energy production. By investing in Littelfuse SPF solar protection fuses, system designers and installers can be confident in the security and efficiency of their photovoltaic investments. Key features and benefits of the Littelfuse SPF015HXR include: * **Specialized PV System Protection:** Designed exclusively for photovoltaic applications, offering tailored protection against reverse overcurrents. * **High Voltage Capability:** UL Listed to safely interrupt faulted circuits at demanding voltage levels common in modern PV systems. * **Midget Style (10 x 38 mm):** Compact form factor suitable for integration into various PV system configurations and enclosures. * **Multiple Ampere Ratings:** Available in a range of current ratings to precisely match specific PV module and conductor protection needs. * **Enhanced System Safety:** Contributes to the overall safety and reliability of solar installations by preventing damage from electrical faults. * **Manufacturer Reputation:** Backed by Littelfuse, a trusted name in circuit protection with decades of experience and innovation in electrical safety solutions. When specifying circuit protection for solar projects, the Littelfuse SPF015HXR stands out as a reliable and compliant solution. Its ability to meet stringent UL requirements for high-voltage PV applications makes it an indispensable component for ensuring the long-term performance and safety of solar energy infrastructure.
  • Specifically designed for photovoltaic (PV) system protection.
  • Midget style fuse (10 x 38 mm) for compact integration.
  • UL Listed for safe interruption of faulted circuits up to demanding voltage levels.
  • Protects PV modules and conductors from reverse overcurrent conditions.
  • Available in multiple ampere ratings to match specific application requirements.

Specifications

Application
1000 VDC PV
Brand Name
Littelfuse
Current Rating
15 A
Series
SPF
Size
10 x 38 mm
Special Features
Solar
Standard
UL 2579 IEC 60269-6
Sub Brand
SPF Series
Type
Full Range

Similar Products

SPF015H

SPF010HXR

Current Rating: 10 A

Series: SPF Solar Protection Fuse

Voltage Rating: 1500 V DC

SPF012HXR

Voltage Rating: 1000 V DC

Current Rating: 12 A

Connection Type: PCB mount / Dead-front holder

SPF005HXR

Voltage Rating: High voltage (PV system levels)

SPF025HXR

SPF015

Voltage Rating: High DC (PV system)

Series: SPF Solar Protection Fuse
