Littelfuse SPF012H - The SPF Solar Protection Fuse series has been specifically designed for the protection of photovoltaic (PV) systems. This family of Midget style fuses (10 x 38 mm) can safely protect PV modules and conductors from reverseovercurrent conditions. As PV systems have grown in size, so have the corresponding voltage requirements. This increase in system voltage has typically been intended to minimize power loss associated with long conductor runs. Standard circuit protection devices are not designed to completely protect photovoltaic panels. However, the SPF series is UL Listed to safely interrupt faulted circuits up to this demanding voltage level. Littelfuse offers multiple ampere ratings to match specific requirements in a variety of applications.
Littelfuse

SPF012H

Alternate Item Number: 0SPF012.H

UPC: 079458169324

Documents & Media
BrochureTechnical BulletinSpecification SheetVideo Clip

Contact for Pricing

Minimum Qty: 100

Multiplier: 100

*Contact for lower quantities*

Overview

The Littelfuse SPF Solar Protection Fuse series, including the SPF012H (SKU: SPF012H), is engineered for the critical protection of photovoltaic (PV) systems. This family of midget-style fuses, measuring 10 x 38 mm, is designed to safely protect PV modules and conductors from reverse-overcurrent conditions. As PV systems grow in size and voltage requirements increase to minimize power loss over long conductor runs, standard circuit protection devices are insufficient. The SPF series is UL Listed to safely interrupt faulted circuits up to a demanding 1000 V dc. Key features include a full-range, fast-acting design that helps eliminate common low-overload faults and prevents power generation losses due to nuisance tripping from temperature changes. The SPF series offers a comprehensive range of ampere ratings from 1 A to 30 A, including 1, 2, 3, 3.5, 4, 5, 6, 8, 10, 12, 15, 20, 25, and 30 A, enabling precise application matching. Installation flexibility is provided through available PCB mount and dead-front holder options. Primary applications for the SPF series include inverters, combiner boxes, and battery charge controllers. Specifications for the SPF012H include a 1000 V dc voltage rating and a maximum interrupting rating of 20 kA for 1-20 A fuses and 50 kA for 25-30 A fuses. The time constant is ≤ 2ms. The fuse features a melamine body and copper alloy caps, and is RoHS compliant. Approvals include UL Listed (File: E339112), CSA Certified (File: 029862_0_000), and TUV (Cert: J 50494849), adhering to UL 248-1 and 248-19, and IEC 60269-6 standards. The SPF012H is manufactured in Mexico. Recommended accessories include the LPHV 1000 V dc POWR-Safe Series Fuse Holder and 125003 Fuse Clips. For technical documents, visit Littelfuse.com/SPF.
  • Designed for photovoltaic (PV) system protection
  • 10 x 38 mm midget-style fuse
  • 1000 V dc voltage rating
  • UL Listed for safe interruption of faulted circuits
  • Full-range, fast-acting for low-overload faults

Specifications

Application
1000 VDC PV
Brand Name
Littelfuse
Current Rating
12 A
Material
Melamine body, Copper alloy caps
Series
SPF
Size
10 x 38 mm
Special Features
Solar
Standard
UL 2579 IEC 60269-6
Sub Brand
SPF Series
Type
Full Range
Voltage Rating
1000 Vdc
Package Weight (Imperial)
0.015 L
Package Weight (Metric)
7.010 g
