Littelfuse SPD2-PV15-3P0 - Surge protection devices (SPDs) provide equipment protection from transient overvoltage events lasting micro-seconds. By limiting the overvoltage to the equipment during these events, costly damage and downtime can be mitigated. The surge protection devices for the 1+0 configuration are available for 60 V to 600 V nominal voltage sub-distribution board applications.
Littelfuse

SPD2-PV15-3P0

Alternate Item Number: SPD2-PV15-3P0

UPC: 079458257540

Documents & Media
BrochureTechnical BulletinSpecification SheetVideo Clip

Contact for Pricing

Overview

The Littelfuse SPD2-PV15-3P0 is a high-performance surge protection device (SPD) engineered to safeguard critical electrical infrastructure from the damaging effects of transient overvoltage events. These rapid, high-energy surges, often lasting mere microseconds, can originate from various sources including lightning strikes, utility switching, and internal equipment faults. Without adequate protection, such events can lead to catastrophic equipment failure, costly repairs, and significant operational downtime, impacting productivity and profitability. Designed for 1+0 configuration sub-distribution board applications, the SPD2-PV15-3P0 offers robust protection across a nominal voltage range of 60V to 600V. This versatility makes it an ideal solution for a wide array of industrial, commercial, and even specialized power systems where reliable equipment uptime is paramount. The device functions by detecting overvoltage conditions and rapidly diverting excess energy away from sensitive connected equipment, effectively clamping the voltage to a safe level. This proactive mitigation strategy is crucial for extending the lifespan of electrical components and ensuring the continuous operation of essential systems. Littelfuse, a globally recognized leader in circuit protection, brings its extensive expertise and commitment to quality to the SPD2-PV15-3P0. This dedication is reflected in the device's durable construction and reliable performance, making it a trusted choice for engineers and facility managers alike. The SPD2-PV15-3P0 is not just a component; it's an investment in operational resilience. Its straightforward integration into existing sub-distribution boards simplifies installation, minimizing disruption and labor costs. By implementing this surge protection, businesses can significantly reduce the risk of unexpected failures, thereby enhancing overall system reliability and reducing the total cost of ownership. Key benefits and features of the Littelfuse SPD2-PV15-3P0 include: * **Superior Transient Overvoltage Protection:** Effectively limits damaging voltage spikes to protect sensitive equipment. * **Wide Voltage Range:** Suitable for nominal voltages from 60V to 600V, offering broad application flexibility. * **1+0 Configuration Design:** Optimized for specific sub-distribution board architectures. * **Costly Downtime Mitigation:** Prevents equipment damage, reducing repair expenses and operational interruptions. * **Enhanced Equipment Lifespan:** Protects components from premature failure caused by voltage transients. * **Trusted Manufacturer:** Backed by Littelfuse's reputation for quality and reliability in circuit protection solutions. When selecting surge protection, consider the specific voltage requirements, potential surge sources, and the criticality of the equipment being protected. The SPD2-PV15-3P0 from Littelfuse stands out as a dependable and effective solution for ensuring the integrity of your electrical systems in demanding environments.
  • Provides robust protection against transient overvoltage events lasting microseconds.
  • Designed for 1+0 configuration sub-distribution board applications.
  • Covers a nominal voltage range from 60V to 600V for broad applicability.
  • Mitigates costly equipment damage and operational downtime.
  • Manufactured by Littelfuse, a trusted leader in circuit protection.

Specifications

Application
Equipment protection from transient overvoltages
Brand Name
Littelfuse
Poles
3+0
Series
PV15
Special Features
DIN Rail Mount
Standard
UL Listed/VDE/IEC
Sub Brand
SPD2 Series
Type
Type 2 Surge Protection Devices
Voltage Rating
60-600 V
