Littelfuse SE-CS30-26 - The SE-CS30 series is a sensitive nickel-core current transformer used with Littelfuse relays to detect low levels of earth-leakage current.
Littelfuse

SE-CS30-26

Alternate Item Number: SE-CS30-26

UPC: 079458989205

Documents & Media
BrochureTechnical BulletinTechnical DrawingSpecification Sheet

Contact for Pricing

Overview

The Littelfuse SE-CS30-26 (SKU: SE-CS30-26) is a sensitive nickel-core current transformer specifically designed for the precise detection of low-level earth-leakage currents. This transformer is engineered to operate in conjunction with Littelfuse relays, ensuring reliable and accurate monitoring within electrical systems. Its primary function is to identify even minor deviations in current that could indicate an earth fault, thereby enhancing safety and preventing potential equipment damage. The robust construction of the SE-CS30-26 series contributes to its dependable performance in industrial and commercial settings where vigilant current monitoring is essential. By providing sensitive detection capabilities, this component plays a crucial role in maintaining the integrity of electrical installations and safeguarding against hazards associated with earth leakage. The SE-CS30-26 is a key component for electrical protection and monitoring strategies requiring high accuracy and sensitivity. Manufactured in the US, it adheres to stringent quality standards for critical applications.
  • Sensitive nickel-core construction for low-level earth-leakage detection
  • Designed for seamless integration with Littelfuse relays
  • Ensures reliable detection of minor earth leakage currents
  • Enhances electrical safety and prevents equipment damage
  • Suitable for industrial and commercial applications

Specifications

Application
Industrial
Brand Name
Littelfuse
Material
Nickel-core
Series
SE-CS30
Special Features
High Quality
Sub Brand
SE CS30 Series
Type
Protection Relays and Controls
Package Weight (Imperial)
0.440 L
Package Weight (Metric)
0.200 kg
