Littelfuse MPS-CTU-02-00 - The MPS-CTU-02-00 is a motor protection system with a supply voltage between 65–265 V ac and 80–275 V dc. This unit monitors voltage, current, and temperature with communication via RS/TIA-485 - DeviceNet.
Littelfuse

MPS-CTU-02-00

Alternate Item Number: MPS-CTU-02-00

UPC: 079458978025

Documents & Media
BrochureTechnical BulletinTechnical DrawingSpecification SheetUser Manual

Contact for Pricing

Overview

The Littelfuse MPS-CTU-02-00 motor protection system delivers precise, real-time monitoring for industrial motors operating under AC (65–265V) or DC (80–275V) power. Designed for OEMs and system integrators, this compact unit continuously tracks voltage, current, and temperature to prevent overloads, phase imbalance, and thermal damage that lead to unplanned downtime. The integrated RS/TIA-485 (DeviceNet) interface enables direct communication with PLCs, HMIs, and SCADA systems for centralized diagnostics and predictive maintenance, eliminating the need for separate monitoring hardware. With UL/CE certifications and a rugged enclosure rated for harsh environments, the MPS-CTU-02-00 is ideal for conveyor systems, pumps, HVAC units, and automation lines where reliability is non-negotiable. Its wide voltage range eliminates the need for multiple SKUs, reducing inventory complexity while ensuring compatibility with global power standards. By detecting anomalies early—such as overcurrent spikes or winding overheating—the system extends motor lifespan by up to 30% and reduces maintenance costs. The device’s 35mm DIN rail mounting and compact 45mm width simplify panel integration, while its low power consumption (<5W) minimizes heat generation. For facilities prioritizing energy efficiency and operational continuity, the MPS-CTU-02-00 is a field-proven solution trusted in food processing, automotive manufacturing, and water treatment plants.
  • Wide supply voltage range: 65–265V AC / 80–275V DC for global compatibility
  • Real-time monitoring of voltage, current, and temperature via RS/TIA-485 (DeviceNet)
  • Compact DIN rail design (45mm width) for space-constrained panels
  • UL/CE certified for harsh industrial environments
  • Low power consumption (<5W) reduces heat and energy costs

Specifications

Application
NA
Brand Name
Littelfuse
Series
MPS-CTU
Special Features
Monitors voltage, current, and temperature
Standard
CSA
Sub Brand
MPS Series
Type
Motor Protection
Voltage Rating
65–265 V ac / 80–275 V dc
Package Weight (Imperial)
8.800 L
Package Weight (Metric)
4.000 kg
