Overview
- 145 VDC Voltage Rating
- 600 A Current Rating
- Compact design with pull-out fuse carrier
- Thermoplastic housing material
- UL Recognized (File: E122674), UL 94 V-0 Flammability Rating
Specifications
Current Rating | 600 A |
Nema Rating | L17T |
Poles | 1P |
Series | L17T |
Series | LTFD |
Series | LTFD6001 |
Series | LTFD Series |
Size | L17T |
Voltage Rating | 145 VDC |
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
MPET4-10R
Modular Emergency Stop - Twist release - Mushroom 40mm - Red - Non-illuminated - - No contact block
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
Frequently Asked Questions
What is the voltage rating for the LTFD6001-00?
The LTFD6001-00 has a voltage rating of 145 Vdc for 70-600 A and 60 Vdc for 800-1200 A.
What is the ampere range for the LTFD6001 series?
The LTFD6001 series has an ampere range from 70 to 1200 A.
What type of fuses are recommended for the LTFD6001 series?
Littelfuse L17T Series fuses are recommended for the LTFD6001 series.
What are the UL approvals for the LTFD6001-00?
The LTFD6001-00 is UL Recognized with File E122674.
What is the flammability rating of the LTFD6001-00?
The LTFD6001-00 has a flammability rating of UL 94 V-0.
What is the contact nut torque for the LTFD6001-00?
The contact nut torque for the LTFD6001-00 is 100 ft-lb.
What is the stud size for the LTFD6001-00?
The stud size for the LTFD6001-00 is 3/4 – 16 x 3.5 in.
Does the LTFD6001-00 have an alarm signaling circuit?
Yes, the LTFD6001-00 includes an alarm signaling circuit.
What is the housing material for the LTFD6001 series?
The LTFD6001 series utilizes a thermoplastic housing material.
How is the fuse replaced in the LTFD6001 series?
The LTFD6001 series utilizes a pull-out fuse carrier for safe disconnection and easy fuse replacement.
