Littelfuse LA30QS70-4 - The Littelfuse LA30QS series Semiconductor protection fuses are intended for the protection of Power Semiconductors such as Diodes, Phase Control SCR and other Power Semiconductor devices. The LA30QS is recommended for new applications providing solutions for your critical protection needs at 300V and less semiconductors. Features: Low l2t minimizes damage to protected components on short circuit. Controlled arc voltage reduces stress to circuit components during fuse clearing. Choice of mounting types provides options for unique termination requirements. Indicator options allow identification of blown fuses. Superior DC capabilities. Applications: Protection of 300 volt heavy duty rectifiers and similar heavy duty power supplies.
Littelfuse

LA30QS70-4

Alternate Item Number: LA30QS704

UPC: 079458161045

Documents & Media
Brochure

Contact for Pricing

Overview

The Littelfuse LA30QS70-4 is a high-performance semiconductor protection fuse engineered to provide critical protection for sensitive power semiconductor devices. Designed for applications operating at 300 volts and below, this fuse is an essential component for safeguarding diodes, phase control SCRs, and other heavy-duty power semiconductor elements. Its robust design and advanced features ensure the longevity and reliability of your power electronic systems. At the core of the LA30QS70-4's protective capabilities is its exceptionally low I²t rating. This specification is paramount in minimizing the energy let-through during a short circuit event. By limiting the I²t, the fuse significantly reduces the thermal stress and potential for catastrophic damage to the protected semiconductor components, thereby extending their operational lifespan and preventing costly downtime. This makes it an ideal choice for new applications demanding the highest levels of protection. Furthermore, the LA30QS70-4 incorporates controlled arc voltage technology. During fuse clearing, the generated arc voltage is carefully managed to prevent excessive stress on other circuit components. This controlled clearing process contributes to overall system stability and reduces the risk of secondary failures, a crucial consideration in demanding industrial environments. Littelfuse understands that system integration requires flexibility. The LA30QS70-4 is available with a choice of mounting types, offering versatile options to accommodate unique termination requirements and installation constraints. This adaptability ensures seamless integration into a wide array of equipment designs. For enhanced operational awareness and simplified maintenance, indicator options are also available, allowing for quick and easy identification of a blown fuse, thus streamlining troubleshooting and replacement procedures. With superior DC capabilities, the LA30QS70-4 is particularly well-suited for protecting 300-volt heavy-duty rectifiers and similar high-power DC supplies. These applications often involve significant current surges and fault conditions, where reliable and rapid fuse protection is non-negotiable. The Littelfuse LA30QS series represents a commitment to quality and performance, offering solutions that meet the stringent demands of modern power electronics. Trust Littelfuse, a recognized leader in circuit protection, for your most critical semiconductor protection needs. Key Features and Benefits: * **Low I²t:** Minimizes damage to protected components during short circuits, enhancing device longevity. * **Controlled Arc Voltage:** Reduces stress on circuit components during fuse clearing for improved system reliability. * **Versatile Mounting Options:** Provides flexibility for unique termination requirements and system integration. * **Indicator Options:** Facilitates easy identification of blown fuses for efficient maintenance. * **Superior DC Capabilities:** Ideal for high-power DC applications, including heavy-duty rectifiers. * **300V Semiconductor Protection:** Specifically designed for safeguarding power semiconductor devices at voltages up to 300V. Applications: * Protection of 300-volt heavy-duty rectifiers. * Protection of similar heavy-duty power supplies. * Safeguarding diodes and phase control SCRs. * Protection for other critical power semiconductor devices in industrial and commercial equipment.
  • Designed for protection of Power Semiconductors (Diodes, Phase Control SCRs)
  • Recommended for new applications at 300V and less
  • Low I²t minimizes damage to protected components on short circuit
  • Controlled arc voltage reduces stress to circuit components during fuse clearing
  • Choice of mounting types and indicator options for flexible integration and maintenance

Specifications

Application
Protection of Semiconductors
Brand Name
Littelfuse
Mounting Type
Choice of mounting types
Series
LA30QS
Special Features
Very-Fast Acting
Standard
UL Recognized
Sub Brand
LA Series
Type
Semiconductor Fuse
Voltage Rating
300 V
