Littelfuse LA100P200-4TI - Littelfuse's LA100P semiconductor protection fuses are rated 1000V, extending the range of protection for UPS systems, AC and DC drives, reduced voltage motor starters and similar applications where lower l2t and superior reliability are needed. With ratings from 15-1000 amperes, a wide range of high voltage applications can be served. Features: Low l2t minimizes damage to protected components on short circuit. Controlled arc voltage reduces stress to circuit components during fuse clearing. Applications: Protection of UPS systems, AC/DC drives, reduced voltage motor starters and other 1000V or less semiconductor devices.
Littelfuse

LA100P200-4TI

Alternate Item Number: LA100P2004TI

UPC: 079458151923

Documents & Media
Brochure

Contact for Pricing

Overview

The Littelfuse LA100P200-4TI is a high-performance semiconductor protection fuse engineered to safeguard critical electrical systems in demanding industrial environments. With a robust 1000V rating, this fuse significantly extends the protective capabilities for a wide array of applications, including Uninterruptible Power Supply (UPS) systems, AC and DC drives, and reduced voltage motor starters. Its advanced design prioritizes superior reliability and minimizes damage to sensitive protected components during fault conditions. At the core of the LA100P200-4TI's effectiveness is its exceptionally low I²t rating. This crucial specification quantifies the let-through energy during a short circuit. By minimizing this energy, the fuse drastically reduces the thermal and physical stress on protected semiconductor devices, such as IGBTs and MOSFETs, thereby preventing catastrophic failures and extending equipment lifespan. This feature is paramount in applications where rapid fault clearing is essential to preserve expensive power electronics. Furthermore, the Littelfuse LA100P200-4TI incorporates controlled arc voltage technology. During the fuse clearing process, a high arc voltage can induce damaging transients in the surrounding circuit. This fuse's controlled arc voltage design mitigates these transients, offering an additional layer of protection for sensitive circuit components and ensuring a cleaner, more reliable interruption. The versatility of the LA100P series is underscored by its broad current rating range, spanning from 15 to 1000 amperes. This extensive range allows for precise selection to match the specific protection requirements of various high-voltage applications, ensuring optimal performance without oversizing or undersizing the protective device. The SKU LA100P200-4TI specifically represents a 200A rating within this series, tailored for applications requiring this precise current handling capability. Key features and benefits of the Littelfuse LA100P200-4TI include: * **Exceptional Semiconductor Protection:** Designed specifically to protect sensitive semiconductor devices from overcurrent and short-circuit events. * **1000V Voltage Rating:** Suitable for a wide range of high-voltage industrial applications. * **Low I²t (Let-Through Energy):** Minimizes damage to protected components during short circuits, preserving equipment integrity. * **Controlled Arc Voltage:** Reduces stress on circuit components during fuse clearing, enhancing overall system reliability. * **Broad Current Rating Range (15-1000A):** Offers flexibility for diverse application needs, with the LA100P200-4TI providing a 200A solution. * **Superior Reliability:** Backed by Littelfuse's reputation for quality and performance in critical protection applications. Applications for the LA100P200-4TI and the broader LA100P series are extensive and critical to modern industrial operations. They are indispensable for ensuring the uptime and longevity of: * **UPS Systems:** Protecting the power electronics that ensure continuous power delivery to critical loads. * **AC/DC Drives:** Safeguarding the complex circuitry within variable frequency drives and motor controllers. * **Reduced Voltage Motor Starters:** Providing essential protection for motor control circuits that reduce inrush current. * **Other 1000V or Less Semiconductor Devices:** Covering a vast array of power electronic applications where robust protection is a necessity. When selecting semiconductor fuses, professionals prioritize manufacturers with a proven track record of innovation and reliability. Littelfuse has long been a trusted name in circuit protection, and the LA100P series exemplifies their commitment to delivering advanced solutions for the evolving demands of industrial power systems. The LA100P200-4TI fuse is an investment in the operational continuity and safety of your most critical electrical infrastructure.
  • 1000V rated semiconductor protection fuse for high-voltage applications.
  • Low I²t minimizes damage to protected components during short circuits.
  • Controlled arc voltage reduces stress on circuit components during fuse clearing.
  • Ideal for UPS systems, AC/DC drives, and reduced voltage motor starters.
  • Part of Littelfuse's reliable LA100P series, offering 15-1000A ratings.

Specifications

Application
Protection of Semiconductors
Brand Name
Littelfuse
Current Rating
200 A
Series
LA100P
Special Features
Very-Fast Acting
Standard
UL Recognized
Sub Brand
LA Series
Type
Semiconductor Fuse
Voltage Rating
1000 V
