Littelfuse JLLS010.TXV - UL CLASS T FAST ACTING T-PACK 10A. Space-saving Class T fuses are the most compact fuses available in ratings above 30 amperes — less than one-third the size of comparable Class R fuses. When rated in accordance with the NEC, Class T fuses provide fast-acting overload and short circuit protection for non-inductive circuits and equipment. Used in inductive circuits, the ampere rating of Class T fuses must be increased to prevent opening on inrush currents. In such instances, Class T fuses may provide only short circuit protection.For motor and general purpose circuits where space is not critical, we recommend POWR-PRO™ JTD_ID Indicator series, LLNRK/LLSRK series, or FLSR_ID Indicator series. Applications: Protection of individual electric services and meters. Main switches containing Class T fuses may be used to provide compact protection for meter stacks. Molded case circuit breaker load centers and panelboards have increased interrupting ratings when “series rated” with Littelfuse Class T fuses. Refer to panelboard manufacturers’ literature for UL Listed combination of fuses and panelboards. Series ratings up to 200,000 amperes are available. Space Saving: Typical three-pole Class T fuse blocks require less than 50percent of the panel area required for Class R fuse blocks. Switch enclosures, fuse pullouts, and other equipment using Class T fuses are often correspondingly more compact. Safety: 200,000 A.I.R. — Reliable interruption of all overcurrents up to 200,000 amperes. Extremely current limiting — Stops damaging short circuit current faster than any mechanical protective device. Fast-Acting — Provides fast-acting overload protection to equipment such as variable speed drives, rectifiers and other equipment containing surge-sensitive components. Longer Equipment Life: Current limiting design greatly reduces damage to equipment caused by heating and magnetic effects of short circuit currents. Economical: Extremely current limiting design often permits use of readily available, less costly equipment. Used as input or output fuses for surge-sensitive components, such as variable speed drives and rectifiers, fast-acting Class T JLLS fuses may prevent opening of expensive semiconductor fuses protecting individual components.
Littelfuse

JLLS010.TXV

UPC: 079458062106

Documents & Media
BrochureSpecification Sheet

Contact for Pricing

Overview

The Littelfuse JLLS010.TXV is a Class T fast-acting fuse designed for compact, reliable protection in non-inductive circuits. With a 10A current rating, this space-saving fuse is less than one-third the size of comparable Class R fuses, making it ideal for applications where panel space is limited. It provides fast-acting overload and short circuit protection, ensuring equipment safety and longevity. Suitable for protecting individual electric services, meters, and surge-sensitive components like variable speed drives and rectifiers, this fuse features a current-limiting design that minimizes equipment damage during short circuits. With a 200,000 A.I.R. rating, it reliably interrupts overcurrents up to 200,000 amperes, offering superior performance in demanding industrial environments. The Littelfuse JLLS010.TXV is a cost-effective solution that enhances equipment reliability and reduces maintenance costs.
  • Fast-acting overload and short circuit protection for non-inductive circuits
  • Compact design, less than one-third the size of Class R fuses
  • 200,000 A.I.R. rating for reliable interruption of high overcurrents
  • Current-limiting design reduces equipment damage during short circuits
  • Ideal for protecting surge-sensitive components like variable speed drives and rectifiers

Specifications

Application
Variable Speed Drives
Brand Name
Littelfuse
Current Rating
10 A
Series
JLLS
Size
Less than one-third the size of comparable Class R fuses
Size
Less than one-third the size of Class R fuses
Special Features
Fast-Acting
Standard
248-15 Class T
Sub Brand
POWR-GARD JLLS Series
Type
Class T
Package Dimensions (L x W x H)
3 IN x 1.75 IN x 1.25 IN
Package Dimensions (L x W x H)
7.62 cm x 4.445 cm x 3.175 cm
Package Weight (Imperial)
0.500 L
Package Weight (Metric)
0.227 kg
