Littelfuse FLSR200 - FLSR200 is a Class RK5 fuse with an ampere rating of 200 and knife-blade-style construction.
Littelfuse

FLSR200

Alternate Item Number: FLSR200.X

UPC: 079458170887

Documents & Media
BrochureTechnical BulletinTechnical DrawingSpecification Sheet

Contact for Pricing

Overview

The **Littelfuse FLSR200** is a high-performance **Class RK5 fuse** engineered for robust industrial circuit protection, featuring a **200A ampere rating** and durable knife-blade-style construction. Designed to meet the rigorous demands of modern power distribution systems, this fuse delivers reliable overcurrent protection in critical applications where downtime is unacceptable. As part of Littelfuse’s industry-leading fuse portfolio, the FLSR200 combines advanced materials, precision engineering, and compliance with stringent safety standards to ensure long-term performance and operational safety. Class RK5 fuses like the FLSR200 are specifically designed for **high-fault current applications**, offering superior interrupting ratings and fast response times to prevent damage to sensitive equipment. The **knife-blade construction** ensures secure, low-resistance connections in compatible fuse blocks, reducing the risk of arcing or loose contacts that could compromise system integrity. With a **200A rating**, this fuse is ideal for protecting heavy-duty industrial machinery, motor control circuits, transformers, and power distribution panels where consistent, dependable protection is essential. **Key Applications & Industries:** - **Motor control centers (MCCs)** – Protects motors from overloads and short circuits in manufacturing plants, HVAC systems, and conveyor systems. - **Power distribution panels** – Safeguards branch circuits in commercial buildings, data centers, and utility substations. - **Industrial machinery** – Used in CNC machines, presses, and robotic systems to prevent catastrophic failures. - **Renewable energy systems** – Provides overcurrent protection in solar inverters and wind turbine controllers. - **OEM equipment** – Integrated into machinery requiring UL/CSA certification for safety compliance. **Why Choose Littelfuse for Class RK5 Fuses?** Littelfuse is a globally recognized leader in circuit protection, with over a century of innovation in fuse technology. The **FLSR200** benefits from Littelfuse’s proprietary **Time-Delay® design**, which allows temporary overloads (e.g., motor startup currents) while still providing fast response to short circuits. This balance of **time-delay and fast-acting performance** minimizes nuisance tripping while ensuring critical protection. Additionally, the fuse’s **high interrupting rating** (typically 200kA) makes it suitable for systems with high prospective fault currents, a common requirement in industrial facilities. **Installation & Compatibility Considerations:** The FLSR200 is designed for use in **Class RK5 fuse blocks and holders**, which are widely available from major electrical equipment manufacturers. Proper sizing and installation are critical—always verify that the fuse’s **ampere rating matches the circuit’s load requirements** and that the fuse block is rated for the fuse type. For applications with **high inrush currents** (e.g., motors, transformers), Littelfuse recommends selecting a fuse with a **time-delay feature** to avoid unnecessary interruptions. Regular inspections should be performed to check for signs of overheating, corrosion, or mechanical damage. **Compliance & Safety:** The FLSR200 meets **UL 248-13 (Class RK5) standards**, ensuring it has been rigorously tested for safety, performance, and reliability. It is also **CSA certified**, making it suitable for use in North American markets. For global applications, Littelfuse offers equivalent fuses that comply with **IEC, VDE, and other international standards**, providing flexibility for multinational projects. **Why Trust Littelfuse?** With a reputation for **quality, innovation, and customer support**, Littelfuse is the preferred choice for engineers and maintenance professionals worldwide. The company’s **application engineering team** provides expert guidance on fuse selection, coordination, and system design, helping customers optimize protection while reducing costs. Whether you’re protecting a single motor or an entire industrial facility, the **Littelfuse FLSR200** delivers the performance, durability, and peace of mind required in today’s high-stakes environments. For dependable circuit protection you can trust, Littelfuse sets the standard.
  • 200A ampere rating for heavy-duty industrial applications
  • Class RK5 design with knife-blade construction for secure connections
  • High interrupting rating (200kA typical) for fault current protection
  • Time-delay feature minimizes nuisance tripping in motor circuits
  • UL 248-13 and CSA certified for North American compliance

Specifications

Application
General Purpose
Brand Name
Littelfuse
Current Rating
200 A
Special Features
Time-Delay
Standard
Standard 248-12 UL Listed/CSA
Sub Brand
POWR-GARD FLSR Series
Type
Class RK5
Package Weight (Imperial)
1.364 L
Package Weight (Metric)
620.000 g
Fuse Block 600VAC 600VDC Class CC 30A 1/4in Quick Connect / Solder 90 angle screw Knob Panel Mount

GPM-SRR90

Fuse Block 600VAC 600VDC Class CC 30A 1/4in Quick Connect / Solder 90 angle screw Knob Panel Mount
Fuse Holder UltraSafe™ 800VAC 1000VDC UL Fuse size 14x51 1-Pole Visual Indicator Microswitch Pressure Plate IP20

C331156

Fuse Holder UltraSafe™ 800VAC 1000VDC UL Fuse size 14x51 1-Pole Visual Indicator Microswitch Pressure Plate IP20
Fuse Block 1500VAC 1500VDC 400A 1-Pole Stud M8

1SCM8

Fuse Block 1500VAC 1500VDC 400A 1-Pole Stud M8
Fuse Holder Modulostar® Size 10x38 IEC 690VAC 690VDC 3-Pole IP20

E1062696

Fuse Holder Modulostar® Size 10x38 IEC 690VAC 690VDC 3-Pole IP20
POWR-JAW clamps improve the contact between fuse and clip. The unnecessary heat from poor contact due to the loss of spring force in the clips can cause nuisance fuse opening and premature aging of surrounding components. High temperature phenolic resin knob designed for the most severe environments 7 sizes to provide effective coverage. Simple design makes installation easy.

LCC5

POWR-JAW clamps improve the contact between fuse and clip. The unnecessary heat from poor contact due to the loss of spring force in the clips can cause nuisance fuse opening and premature aging of surrounding components. High temperature phenolic resin knob designed for the most severe environments 7 sizes to provide effective coverage. Simple design makes installation easy.
9F61 Size B Clips 1.6in

9F61BWW460

9F61 Size B Clips 1.6in
