Littelfuse FLSR020ID - FLSR020ID is a Class RK5 fuse with an ampere rating of 20 and cartridge-style construction.
Littelfuse

FLSR020ID

Alternate Item Number: FLSR020.TXID

UPC: 079458025385

Documents & Media
BrochureTechnical BulletinTechnical DrawingSpecification Sheet

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Overview

The **Littelfuse FLSR020ID** is a high-performance **Class RK5 cartridge fuse** engineered for robust industrial circuit protection. With a **20-ampere rating**, this fuse is designed to safeguard critical electrical systems against overloads, short circuits, and ground faults, ensuring operational continuity and equipment safety. As part of Littelfuse’s industry-leading circuit protection portfolio, the FLSR020ID combines precision engineering with durable construction to deliver consistent performance in demanding environments. Class RK5 fuses are widely recognized for their **superior interrupting ratings** and **fast-acting response**, making them ideal for protecting sensitive industrial equipment such as motors, transformers, switchgear, and distribution panels. The **cartridge-style design** of the FLSR020ID ensures compatibility with standard RK5 fuse holders, simplifying installation and maintenance while minimizing downtime. Unlike generic fuses, RK5-class fuses meet stringent **UL 248 standards**, providing an added layer of reliability for professionals who prioritize safety and compliance. **Key Applications & Industries:** The FLSR020ID is a versatile solution for a broad range of industrial applications, including: - **Motor circuits** in manufacturing plants, where overload protection prevents costly damage to motors and associated equipment. - **Transformer protection** in substations and power distribution systems, where precise fault interruption is critical. - **Control panels and switchgear**, where RK5 fuses provide backup protection for branch circuits. - **Renewable energy systems**, including solar inverters and wind turbine controllers, where reliable fault isolation is essential. - **Data centers and critical infrastructure**, where uptime is non-negotiable and fuses must respond rapidly to faults. **Why Choose Littelfuse for Class RK5 Protection?** Littelfuse has been a trusted name in circuit protection for over a century, setting the benchmark for innovation and reliability in industrial safety. The **FLSR020ID** leverages Littelfuse’s proprietary **Time-Temperature-Tested® (TTT) design**, which ensures consistent performance across varying load conditions and ambient temperatures. This fuse is **UL Listed and CSA Certified**, meeting global safety standards and providing peace of mind for engineers and maintenance teams. **Installation & Maintenance Considerations:** Proper selection and installation of the FLSR020ID are straightforward due to its **standard cartridge dimensions** (1/4" x 1-1/4") and **color-coded end caps** for easy ampere identification. When replacing fuses, professionals should: - Verify the **ampere rating** matches the circuit requirements to avoid nuisance tripping or inadequate protection. - Inspect fuse holders for signs of wear or corrosion before installation to ensure a secure connection. - Follow **OSHA and NFPA 70E** guidelines for electrical safety, including proper PPE and lockout/tagout procedures. - Consider **coordination studies** when integrating the FLSR020ID into larger protection schemes to ensure selective tripping and minimize system-wide outages. **Performance & Reliability:** The FLSR020ID’s **high interrupting rating** (typically 200,000 amperes) ensures it can safely interrupt fault currents in high-fault systems, such as those found in industrial facilities. Its **low let-through energy (I²t)** helps reduce stress on downstream equipment during fault conditions, extending the lifespan of motors, cables, and other components. Additionally, the fuse’s **non-aging design** maintains consistent performance over time, reducing the need for frequent replacements. For industries where **downtime is costly**, the FLSR020ID delivers unmatched reliability. Whether deployed in harsh environments like chemical plants, mining operations, or food processing facilities, this fuse’s **robust construction** resists vibration, shock, and temperature extremes. Littelfuse’s global distribution network ensures quick availability, while their technical support team provides expert guidance on fuse selection, application-specific requirements, and compliance with local codes. **Conclusion:** The **Littelfuse FLSR020ID Class RK5 fuse** is more than just a protective component—it’s a critical safeguard for industrial electrical systems. By combining **superior fault interruption**, **durable construction**, and **Littelfuse’s legacy of innovation**, this fuse delivers the performance and reliability that professionals demand. Whether protecting motors, transformers, or control panels, the FLSR020ID ensures that your operations run smoothly, safely, and efficiently. Trust Littelfuse to keep your electrical systems secure, compliant, and optimized for peak performance.
  • 20A Class RK5 cartridge fuse for industrial circuit protection
  • High interrupting rating (200kA) for fault current interruption
  • UL 248 Listed and CSA Certified for global compliance
  • Fast-acting response to protect motors, transformers, and switchgear
  • Durable construction for harsh industrial environments

Specifications

Application
General Purpose
Brand Name
Littelfuse
Current Rating
20 A
Material
Cartridge-style construction
Mounting Type
Cartridge fuse holder
Series
Class RK5
Size
Cartridge-style
Size
1/4" x 1-1/4"
Special Features
Time-Delay
Standard
Standard 248-12 UL Listed/CSA
Sub Brand
POWR-GARD FLSR Series
Type
Class RK5
Package Weight (Imperial)
0.180 L
Package Weight (Metric)
0.082 kg
