Contact for Pricing
Minimum Qty: 100
Multiplier: 100
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 2 SPDT auxiliary switches for 3-pole systems
- NO/NC changeover contacts
- UL 60947-5-1 compliant
- Supports 12.5mA/24V standard or 1mA/4V low-level signals
- 10A thermal current rating and 10,000 operations
Specifications
Current Rating | 10 A |
Ip Rating | IP2x |
Mounting Type | Screw |
Poles | 3 poles |
Series | CON-AUX |
Frequently Asked Questions
What is the current rating for the HCD auxiliary switch?
The HCD auxiliary switch has a current rating of 10 A per circuit.
What is the voltage specification for the CON-AUX300-2 model?
The CON-AUX300-2 model has a voltage specification of 250 V.
What are the dimensions of the CON-AUX300-2 auxiliary switch?
The CON-AUX300-2 measures 3.677 inches in height, 0.689 inches in length, and 1.803 inches in width.
What certification does the HCD auxiliary switch comply with?
The HCD auxiliary switch complies with UL 508 certification, with File No. E227250.
What type of circuit configurations are available for the HCD auxiliary switch?
The HCD auxiliary switch offers SPDT circuits, and 1 NO/NC configurations for single unit interlock.
What are the terminal connection types for the HCD auxiliary switch?
It features 0.250” quick connects for power terminal connections and #6-32 screw terminals for single unit interlock.
What is the mounting method for the HCD auxiliary switch?
The HCD auxiliary switch is designed for chassis mount installation.
What is the primary application for the HCD auxiliary switch?
The HCD auxiliary switch is designed as an accessory for 3-pole contactors and is used in HVAC/R applications.
What is the maximum number of single unit interlocks that can be configured?
A maximum of two single unit interlocks can be configured, with one on each side of the contactor.
What is the arrangement of the HCD auxiliary switch?
The arrangement is 1 NO/NC (break before make) for single unit interlock, and SPDT for other configurations.
