Littelfuse 201-200-SP-DPDT 1-PH 8-PIN PLUG-IN VM / 190 -

Model OT08PC octal socket is required for the UL rating.

The 201-200-SP-DPDT model is used on 190-240VAC, 50/60Hz motors.

The operating ambient temperature range is -20° to 70°C (-4° to 158°F).

The restart delay time after a fault or complete power loss is 2 seconds.

The fixed trip delay of 4 seconds prevents nuisance tripping due to rapidly fluctuating power line conditions.

The output contacts have a general purpose rating of 10A @ 240VAC.

Yes, the OT08PC socket can be surface mounted or installed on a DIN Rail.

The manufacturer's recommended screw terminal torque for the RB Series and OT Series Octal Sockets is 12 in.-lbs.

The microcontroller-based circuitry constantly monitors voltage to detect harmful power line conditions before the motor starts.

The maximum input power consumption is 5 W.
