Littelfuse 0LGR.500UXL - The Littelfuse® POWR-PRO® JTD_ID Indicator Class J fuse provides visual blown fuse indication and maximum protection in a compact package. The compact Class J package was designed specifically for circuits where space is at a premium. The current limiting time delay JTD_ID offers a patented true dual-element design that is ideal for use in circuits with high inrush currents. Superior performance characteristics of JTD_ID Indicator fuses reduce nuisance fuse opening and the blown fuse indication reduces downtime and increases safety.
Littelfuse

0LGR.500UXL

Alternate Item Number: 0LGR.500UXL

UPC: 079458946024

Documents & Media
BrochureTechnical BulletinSpecification Sheet

Contact for Pricing

Minimum Qty: 500

Multiplier: 500

*Contact for lower quantities*

Overview

The Littelfuse® POWR-PRO® JTD_ID Indicator Class J fuse, SKU 0LGR.500UXL, delivers advanced circuit protection in a compact Class J package, specifically designed for space-constrained industrial applications. This fuse features a patented true dual-element design, offering current-limiting time-delay characteristics essential for circuits experiencing high inrush currents, such as motor loads and transformers. The JTD_ID series is engineered to significantly reduce nuisance fuse openings, thereby minimizing costly operational downtime. A key benefit is the integrated visual blown fuse indication, which allows for rapid identification of fuse status, accelerating troubleshooting and enhancing overall system safety. The compact Class J design ensures it fits seamlessly into tight enclosures, making it suitable for Motor Control Centers (MCCs), Power Distribution Units (PDUs), industrial machinery, renewable energy systems, and HVAC applications. Littelfuse, a global leader in circuit protection, ensures superior performance and reliability with its POWR-PRO® series. The 0.5A JTD_ID fuse is designed for straightforward installation and maintenance, compatible with standard Class J fuse holders. For optimal performance, verify compatibility, adhere to proper sizing guidelines, conduct regular inspections, and utilize genuine Littelfuse parts. This fuse represents a strategic investment for reducing downtime, enhancing safety, and optimizing system performance in critical industrial operations.
  • Compact Class J package ideal for space-constrained applications.
  • Patented true dual-element design for high inrush current protection.
  • Current-limiting time-delay characteristics reduce nuisance openings.
  • Visual blown fuse indication for quick troubleshooting and safety.
  • Superior performance and reliability from Littelfuse POWR-PRO® series.

Specifications

Amperage Rating
4000 Amps
Application
Protection of Semiconductors
Brand Name
Littelfuse
Series
JTD_ID
Size
Compact Class J
Special Features
Very-Fast Acting
Standard
UL Recognized
Sub Brand
POWR-GARD LA15QS Series
Type
Semiconductor Fuse
