FS100KHR

The FS100KHR transformer has a primary voltage of 380/347 volts at 50/60 Hertz.

The FS100KHR transformer provides a secondary voltage of 12 x 24 volts.

The VA rating for the FS100KHR transformer is 100 VA, with a CE VA rating of 100 VA.

The FS100KHR transformer has output amps of 8.33/4.17 (primary/secondary).

The approximate shipping weight of the FS100KHR transformer is 4.2 pounds.

The transformer comes with a 15-year warranty.

The transformer is CSA Certified, UL Listed, CE Marked, and RoHS Compliant.

The transformer features a rugged TYPE 1 enclosure with split side covers that provide easy access to the wiring compartment.

The transformer uses superior insulating materials with 130°C (50-1500 VA) - Class B 95°C Temperature Rise.

The transformer offers easy mounting via four mounting slots and two keyhole slots.
