Overview
- Dual independent thermostats for heaters and alarms
- 0-60°C adjustment range with +/- 4K switching tolerance
- N.C./N.C. spring contacts, 240 VAC/10A (N.C.), 120 VAC/15A (N.O.), 30W DC max
- Flame-retardant UL94VO plastic, IP20 protection
- Mounts on 35mm DIN rail; screw terminals for AWG 14 (2.5mm²)
Specifications
Brand Name | Hammond Mfg. |
Current Rating | 10 A (N.C.) / 15 A (N.O.) |
IP Rating | IP20 |
Material | UL94VO plastic |
Mounting Type | 35 mm DIN Rail |
Poles | N.C./N.O. Contacts |
Sub Brand | SKTD Series |
Voltage Rating | 240 VAC/120 VAC |
Package Dimensions (L x W x H) | 1 IN x 1 IN x 1 IN |
Package Dimensions (L x W x H) | 2.54 cm x 2.54 cm x 2.54 cm |
Package Weight (Imperial) | 1.000 L |
Package Weight (Metric) | 0.454 kg |
52615500
TSTAT A19ABA-46D,50-130F,SPST, Bulletin MCLP (Non-DPS Service Parts - McLean non-distributor product scope (DPS) Service Parts), Material: Plastic, Finish:Frequently Asked Questions
What is the switching tolerance of the SKTD542C?
The switching tolerance is +/- 4K.
What is the temperature adjustment range for the SKTD542C?
The SKTD542C has an adjustment range of 0-60°C (32-140°F).
What is the switching capacity of the N.C. contacts?
The N.C. contacts have a switching capacity of 240 VAC / 10A.
What is the switching capacity of the N.O. contacts?
The N.O. contacts have a switching capacity of 120 VAC / 15A, with a DC max of 30 watts.
How is the SKTD542C mounted?
The SKTD542C features clip mounting for easy installation on a 35 mm DIN rail.
What type of plastic is the housing made from?
The housing is constructed from flame-retardant UL94VO plastic.
What is the IP protection rating of this thermostat?
The SKTD542C offers IP20 protection.
What are the approvals for the SKTD542C?
The SKTD542C is UL Recognized Component, cUL Recognized Component, and CE approved.
