Hammond Manufacturing RB-WR2 - 2U 6"D Rack Basics Fixed Depth Wall Bracket
Hammond Manufacturing

RB-WR2

UPC: 623980777955

Documents & Media
Technical DrawingSpecification SheetWarranty

Contact for Pricing

Overview

The Hammond RB-WR2 is a 2U, 6-inch deep fixed-depth wall bracket designed for secure mounting of rack-mountable equipment. Manufactured by Hammond Manufacturing, this bracket is part of their Rack Basics series, offering a straightforward and reliable solution for wall-mounted installations. It features tapped holes per the EIA Universal pattern standard (12-24UNC) for versatile equipment attachment. Constructed from steel with a black textured, low-gloss polyester powder paint finish (RAL 9005), it supports a static load rating of 100 lbs. Made in the USA.
  • 2U Rack Unit Height
  • 6-inch Fixed Depth
  • EIA Universal pattern (12-24UNC) tapped holes
  • 100 lbs. static load rating
  • Durable steel construction with RAL 9005 black textured finish

Specifications

Brand Name
Hammond Mfg.
Color
Black
Material
Steel
Mounting Type
Wall Mount
Mounting Type
Wall Bracket
Series
Rack Basics
Size
2U 6"D
Sub Brand
RB-WR Series
Package Dimensions (L x W x H)
6.6 IN x 21.3 IN x 3.98 IN
Package Dimensions (L x W x H)
16.764 cm x 54.102 cm x 10.1092 cm
Package Weight (Imperial)
2.600 L
Package Weight (Metric)
1.179 kg
