Hammond Manufacturing PJSPU1412 - Swing Panel - 13.64 x 11.16 - Alum

Hammond Manufacturing PJSPU1412 Swing Panel - 13.64 x 11.16 - Alum

UPC: 623980020921


Documents & Media
Technical DrawingSpecification SheetWarranty

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The Hammond Manufacturing Swing Panel, SKU PJSPU1412, is a hinged aluminum access panel designed for PJU and PJ Series enclosures. Measuring 13.64 inches high by 11.16 inches wide, this panel offers front-mounted access to internal enclosure components without requiring additional drilling. Constructed from durable 5052-H32 aluminum alloy, it provides corrosion resistance suitable for industrial applications. The panel features corner sliders for adjustable depth settings and can be installed to swing either left or right. Electrical continuity is maintained via a bonding stud on the door and a grounding stud on the enclosure. This panel is ideal for instrument enclosures, control housings, and terminal wiring applications.
  • Hinged aluminum access panel for PJU and PJ Series enclosures
  • Dimensions: 13.64" H x 11.16" W
  • Constructed from durable 5052-H32 aluminum alloy for corrosion resistance
  • Adjustable depth settings with corner sliders
  • Front-mounted access with left or right swing capability

Specifications

Brand Name
Hammond Mfg.
Material
Aluminum
Mounting Type
Swing Panel with Corner Sliders
Mounting Type
Front-mount without drilling
Series
PJU/PJ Series
Series
PJU and PJ Series
Size
13.64 x 11.16
Size
13.64 x 11.16 in
Size
13.64 x 11.16 inches
Sub Brand
PJ/PJU Series
Package Dimensions (L x W x H)
1 IN x 1 IN x 1 IN
Package Dimensions (L x W x H)
2.54 cm x 2.54 cm x 2.54 cm
Package Weight (Imperial)
6.000 L
Package Weight (Metric)
2.722 kg
PolyPro Swing-Out Panel Adjustable, 8.75x6.88, Anodized, Aluminum

A108PSWPNL

PolyPro Swing-Out Panel Adjustable, 8.75x6.88, Anodized, Aluminum
Swing Panel - 17.25 x 15.38 - Alum

PJSP1816

Swing Panel - 17.25 x 15.38 - Alum
Busbar support SB C 30 10mm 3P

50245300

Busbar support SB C 30 10mm 3P
ARCA JIC 12 x 10 x 5 with knockouts, hinged flat opaque cover, SS latch, padlockable, SS mounting feet

ARK12105CHFSSLM

ARCA JIC 12 x 10 x 5 with knockouts, hinged flat opaque cover, SS latch, padlockable, SS mounting feet
10x8x4 Polycarbonate Enclosure NEMA 6P | Standard Hinge | Clear Lid | Integrated Locking Latch | Intergrated Mounting Flange

P10084C

10x8x4 Polycarbonate Enclosure NEMA 6P | Standard Hinge | Clear Lid | Integrated Locking Latch | Intergrated Mounting Flange
Universal raintight hubs are rated for outdoor enclosures and come in a variety of sizes for every ABB load center or panel. The TC150 has a diameter of 1.50" and has a base size of 3".

TC150

Universal raintight hubs are rated for outdoor enclosures and come in a variety of sizes for every ABB load center or panel. The TC150 has a diameter of 1.50" and has a base size of 3".
PVC Coated F Service Head, Threaded Rigid, Conduit Size 1 Inch, Number and Diameter of Knockouts Two at 7/16 Inch, Three at 1/2 Inch, Aluminum,Gray

F385-G

PVC Coated F Service Head, Threaded Rigid, Conduit Size 1 Inch, Number and Diameter of Knockouts Two at 7/16 Inch, Three at 1/2 Inch, Aluminum,Gray
PJ Series Mounting Feet (Set of 4) - Fits 6 x 6 to 20 x 16 - 316 SS

PJW4NFS

PJ Series Mounting Feet (Set of 4) - Fits 6 x 6 to 20 x 16 - 316 SS

Frequently Asked Questions

What material is the swing panel made of?

The swing panel is made of hinged aluminum.

Which enclosure series is the PJSPU1412 compatible with?

The PJSPU1412 swing panel is designed for use with PJU Series Enclosures.

What are the dimensions of the PJSPU1412 swing panel?

The PJSPU1412 swing panel has a height of 13.64 inches and a width of 11.86 inches.

How is the swing panel installed?

The swing panel mounts at the front of the enclosure body and is field installed with no drilling required.
