Hammond Manufacturing HYPB2SS HYGIENIC N4X 30MM 2PB

The enclosure complies with UL 508A Type 3R, 12, 4, 4X, CSA Type 3R, 12, 4, 4X, NSF – ANSI 169, NEMA 3R, 12, 4, 4X, and IEC 60529, IP69, IP69K.

The enclosure is constructed from formed 304 stainless steel with continuously welded seams ground smooth.

The cover and enclosure have a natural stainless steel finish with a smooth #4 dairy finish.

The sides are sloped on 4 sides to prevent water from resting on top, regardless of enclosure orientation.

It features hex head design screws and a door-edge mounted silicone gasket for easy cleaning in hose-down environments.

Yes, the gasket can be easily removed and re-installed for cleaning or replacement, and additional gaskets can be ordered separately.

The enclosure offers multiple pushbutton hole configurations with either 22.5mm or 30.5mm notched holes.

No, there are no pre-drilled wall mounting holes, allowing for flexible mounting alternatives like weld-in-place or stand-offs.

A bonding stud is provided on the door and a grounding stud is installed in the enclosure.

The HYPB2SS enclosure has a height of 7.94 inches, a width of 4.88 inches, and a depth of 4.00 inches.
