UPC: 623980053523
Documents & Media
Contact for Pricing
Overview
- 75mm wide plated steel construction for durability
- 750mm length for vertical mounting applications
- Flush mount bracket design for a clean installation
- Alternating square and round holes for versatile equipment attachment
- Sold in pairs with included butt end bracket
Specifications
Brand Name | Hammond Mfg. |
Material | Plated Steel |
Material | 14 gauge galvanized steel |
Mounting Type | Flush Mount |
Mounting Type | Flush Mounting |
Series | HGV |
Size | 75mm x 750mm |
Sub Brand | HMEGS Series |
Package Dimensions (L x W x H) | 1 IN x 1 IN x 1 IN |
Package Dimensions (L x W x H) | 2.54 cm x 2.54 cm x 2.54 cm |
Package Weight (Imperial) | 8.000 L |
Package Weight (Metric) | 3.629 kg |
ZL16
Clamp for NEMA 4 /4X (1), Bulletin A80 (Accessories - Misc. - Latch, Locks, Clamps, Grounding Device, Flush Mount Door Frames)
AF76FPT
Front hinge to box 20" front with quarter turn locks for flush mounted ReliaGear lightings panels. Quarter turn locks are required for XT5 and XT6 panelboard configurations, but can be used with other applications as well. Front hinged to box is similar to door-in-door for convenient access to gutters, but more economically priced. A contractor must remove four screws to access the outer door.
SBS
Adjustable far-side box stabilizer for electrical boxes. It clips on electrical boxes for additional support and is made of spring steel. The trade size is for 2-1/2" thru 4" metal studs, and the color is black.
OWC
Old Work Box Support Clip. Clips Lock Old-Work Steel Switch Boxes Tightly To Wall Plaster, Dry Wall, Concrete Block, Brick Or Concrete. Adapts To Any Wall Thickness Up To 3/4 Inch
Frequently Asked Questions
What are the hole types on the HGV75 grid strap?
The HGV75 features alternating square holes for cage nuts and round holes for M5 or #12 screws.
What is the hole spacing on the HGV75 strap?
The HGV75 grid strap has standard 25mm hole centers.
How is the HGV75 strap designed for flush mounting?
The HGV75 attaches to other straps using an included butt end bracket for a smooth, continuous surface.
Can two HGV75 straps be combined for full height?
Yes, two 75mm depth grid straps can be used together to achieve a full-height vertical strap configuration.
What material is the Hammond HGV75 strap made from?
The Hammond HGV75 is constructed from plated steel.
