Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 50-piece kit of 12-24 CAGNUTS and screws
- Durable metal construction
- Common 12-24 thread size
- Manufactured in the USA
- Ideal for industrial assembly and maintenance
Specifications
Brand Name | Hammond Mfg. |
Sub Brand | CAGKIT Series |
Package Dimensions (L x W x H) | 1 IN x 1 IN x 1 IN |
Package Dimensions (L x W x H) | 2.54 cm x 2.54 cm x 2.54 cm |
Package Weight (Imperial) | 1.000 L |
Package Weight (Metric) | 0.454 kg |
22504SP
A tamperproof machine screw with a button head and socket pin drive. It is made of 18-8 stainless steel with a stainless finish for general atmospheric corrosion resistance. The screw is size #6 x 1/4 in. with 2A external threads and 32 TPI.
Frequently Asked Questions
What specific part number is for a 50-piece kit with 12-24 thread size?
The part number for a 50-piece kit with 12-24 thread size is CAGKIT1224-50.
What thread sizes are available for the CAGKIT Series?
The CAGKIT Series is available in 10-32, 12-24, and M6 thread sizes.
What is included in the CAGKIT Series mounting hardware kit?
Each kit includes matching rack screws with captive nylon washers and zinc-plated cage nuts.
What type of rack rails are compatible with these cage nuts?
The cage nuts fit standard 3/8-inch (9.54 mm) square-hole rack rails.
What are the CAGKIT Series kits available in?
Kits are available in 25, 50, and 100-piece quantities, depending on the thread size.
What are the screws made of and do they have washers?
The screws are made of heat-treated steel and include captive nylon washers.
What are the cage nuts made of?
The cage nuts are made of zinc-plated spring steel.
What is the purpose of the self-guiding pilot point screws?
They help align equipment quickly and reduce cross-threading during installation.
What is the benefit of the captive nylon washers?
They help protect painted rack rails and equipment faceplates from scratches.
What types of equipment can be mounted using this kit?
This kit can mount servers, switches, patch panels, PDUs, UPS systems, and AV equipment.
