Overview
- Constructed from solid 0.125" copper for durability and conductivity.
- Features multiple 10-32 drilled and tapped holes for consolidated grounding points.
- Includes one 0.312" main ground point for primary connections.
- Designed for direct mounting to grid straps or frame mounting surfaces.
- Kit includes copper busbar, 10-32 x 0.5" screws, and flat washers.
Specifications
Brand Name | Hammond Mfg. |
Connection Type | Screw Terminal |
Material | Copper |
Mounting Type | Direct Mount |
Size | 2x10 in |
Size | 2x10 inch |
Sub Brand | BUSBAR Series |
Package Dimensions (L x W x H) | 1 IN x 1 IN x 1 IN |
Package Dimensions (L x W x H) | 2.54 cm x 2.54 cm x 2.54 cm |
Package Weight (Imperial) | 3.500 L |
Package Weight (Metric) | 1.588 kg |
HB01008
FLEX, TERM, 64MM (3), Bulletin HB2 (Busbar Components), Size/Dims: 94x45x154mm, Material/Finish:
251-31446-10
Bus-Bar Tap - Straight Barrel Angle for Busbar Width 4, Wire Range 500 KCMIL 350, 925/24 Flex, 600V to 35KV, Die Color Pink
Frequently Asked Questions
What material is the BUSBAR2X10 busbar made of?
The BUSBAR2X10 busbar is constructed from electro tin-plated copper.
Is the BUSBAR2X10 compliant with RoHS standards?
Yes, the BUSBAR2X10 is RoHS Compliant.
Where is the BUSBAR2X10 manufactured?
The BUSBAR2X10 is manufactured in North America.
What are the dimensions of the BUSBAR2X10 busbar?
The BUSBAR2X10 busbar has a thickness of 0.25 inches, a width of 2.00 inches, and a length of 10.00 inches.
How many ground points does the BUSBAR2X10 offer?
The BUSBAR2X10 busbar provides 12 ground points.
What is the mounting bracket hole diameter?
The mounting bracket holes have a diameter of 0.375 inches.
What is the ampacity of the BUSBAR2X10 busbar?
The busbar has an ampacity of 710 amps at a 30°C rise, 940 amps at a 50°C rise, and 1100 amps at a 65°C rise.
What size are the ground lug holes on the BUSBAR2X10?
The ground lug holes on the BUSBAR2X10 are 9/32" in diameter.
What is the operating temperature for ampacity ratings?
The ampacity ratings are based on an indoor ambient temperature of 40°C at 60 Hz.
What hardware is included with the busbar?
It includes 12 each of ¼-20 x 0.75” stainless steel Phillips machine screws, ¼ stainless steel lock washers, and ¼-20 stainless steel hex nuts.
