Ferraz Shawmut H080645 - CC851 CP GRB 20 127 80
Ferraz Shawmut

H080645

UPC: 60534004087

Contact for Pricing

Overview

The Mersen FR27GB80V80T (SKU: H080645) is an 80A high-speed fuse specifically designed for semiconductor protection. Manufactured by Mersen (formerly Ferraz Shawmut), this cylindrical fuse-link is classified as gRB, indicating its suitability for fast-acting protection of sensitive electronic components. It operates at a voltage rating of 800V AC and features a high breaking capacity of 90 kA. Key specifications include a melting I²t of 11,000 A²s and a power dissipation of 11.5W. The fuse meets IEC standards for high-speed protection and has dimensions of 27x60mm. This product is ideal for industrial applications requiring rapid fault interruption to safeguard semiconductor circuits. Distributed by Gross Automation.
  • 80A Current Rating for robust protection
  • 800V AC Voltage Rating suitable for industrial power systems
  • 27x60mm Compact cylindrical form factor
  • 90 kA Tested Interrupting Rating for high fault current handling
  • gRB Class for specialized semiconductor protection

Specifications

Current Rating
80 A
Series
CC851
Size
27x60mm
Voltage Rating
800 V AC
