Contact for Pricing
Overview
- IECEx and ATEX certified for Zone 1 hazardous locations (Ex d IIB T4 Gb, Ex tb IIIB Db)
- 110VDC operation
- Marine-grade alloy body with toughened glass dome and stainless steel guard
- IP66 ingress protection against dust and water
- Operating temperature range: -40°C to 70°C
- Four M20 x 1.5 cable entries for easy wiring
- 5,000-hour lamp life
- Colored xenon lenses available separately
Specifications
-40 to 158 | DEG F |
0.92 | A |
110 | VAC |
110VAC | V |
5,000 | HR |
9.84 H x 10.04 W x 8.23 D | IN |
Amperage | 0.92 A |
Amperage Rating | 0.92 AMP |
Application | Indoor/Outdoor |
Average Life | 5,000 HR |
Brand Name | Federal Signal |
Color | Colored Lens Sold Separately |
Color | Red |
Environmental Conditions | -40 to 158 DEG F |
Light Source | Xenon Tube |
Material | Cast Aluminum Housing/Stainless Steel External Hardware |
Model | XEN4 |
Mounting | Surface |
NEMA Rating | IP66 Enclosure |
Operating Temperature | -40D to +158DF (-40D to +70DC) |
Shape | Cylindrical |
Size | 9.84 H x 10.04 W x 8.23 D IN |
Special Features | For use In Hazardous Locations Requiring ATEX Approval |
Standard | ATEX Certified/IECEx Certified/CE Certified |
Standard | ATEX,CE,IECEx |
Style | Simulated Rotating Beacon |
Type | Flameproof Strobe Light |
Voltage Rating | 110VAC |
Voltage Rating | 110 VAC |
Package Dimensions (L x W x H) | 11.19 IN x 13.56 IN x 12.13 IN |
Package Dimensions (L x W x H) | 28.4226 cm x 34.4424 cm x 30.8102 cm |
Package Weight (Imperial) | 16.500 L |
Package Weight (Metric) | 7.484 kg |
