Overview
- Wide voltage range 48‑240 VAC for flexible installation
- UL and cUL certified for safety compliance
- Red LED visual cue combined with audible alarm
- Panel‑mount design for secure, permanent installation
- Rugged construction protects against dust, moisture, and vibration
Specifications
-22 to 140 | DEG F |
0.03 @ 48VAC/0.02 @ 240VAC | A |
140-160 (Flash Mode) | FLPM |
150 (+/- 10) Flash Mode | FLPM |
2.74 H x 1.61 W x 1.61 D | IN |
48-240 | VAC |
48-240VAC | V |
50,000 | HR |
75 | dBa |
85 | dBa |
Amperage | 0.03 @ 48VAC/0.02 @ 240VAC A |
Application | Indoor/Outdoor |
Average Life | 50,000 HR |
Brand Name | Federal Signal |
Color | Red |
dBa at 10ft | 75 dBa |
dBa at 1M | 85 dBa |
Diameter | 1.61 in (40.9 mm) |
Environmental Conditions | -22 to 140 DEG F |
Flashes Per Minute | 140-160 (Flash Mode) FLPM |
Flashing Pattern | Steady/Flashing |
Lens Color | Red |
Light Source | LED |
Loudness | 85 at 1 Meter DB |
Model | PMC |
Mounting | Panel |
NEMA Rating | Type 3R, IP65, IP69K Enclosure |
Operating Temperature | -22D to +140DF (-30D to +60DC) |
Shape | Cylindrical |
Size | 2.74 H x 1.61 W x 1.61 D IN |
Special Features | Three Levels Of Alarm Controlled Via Independent Contacts |
Standard | UL Listed/cUL Listed/CE Certified |
Standard | CE,UL,cUL |
Style | Audible/Visual |
Type | Panel Mount Multifunctional LED Audible-Visual Signal |
Voltage Rating | 48-240VAC |
Voltage Rating | 48-240 VAC |
Package Dimensions (L x W x H) | 2.4 IN x 2.4 IN x 3.4 IN |
Package Dimensions (L x W x H) | 6.096 cm x 6.096 cm x 8.636 cm |
Package Weight (Imperial) | 0.340 L |
Package Weight (Metric) | 0.154 kg |
