AMR6-2570K

The AMR6 is a high-quality ceiling speaker for public address and music in industrial, municipal, and commercial office environments.

The AMR6-2570K has 8-watt power handling with transformer taps at 8, 4, 2, 1, and 0.5 watts.

The AMR6-2570K operates in 25 Vrms or 70 Vrms systems.

The AMR6-2570K has a frequency response range of 110Hz to 20,000Hz.

The AMR6-2570K has an SPL of 92 dBa at 10 feet and 102 dBa at 1 meter, both at 8 watts.

The operating temperature range for the AMR6-2570K is 32°F to 120°F (0°C to 49°C).

The AMR6-2570K has a diameter of 9.41 inches (239.0 mm) and a depth of 4.33 inches (110.0 mm).

The speaker is designed to mount flush in a ceiling or wall cavity using quick-release torsion spring mounting. A back box and tile bridge are included.

The AMR6-2570K speaker weighs 3.06 lbs (1.39 kg), with a shipping weight of 4.75 lbs (2.15 kg).

The AMR6-2570K utilizes both a woofer and a neodymium tweeter to reproduce a full range of voice, music, and tones.
