Overview
- Adjustable sensing distance: 4–12mm (factory-set at 7mm)
- Multi-voltage supply: 20.4 to 255 VAC/DC
- SPDT relay output rated 2A at 240VAC
- ON-delay time adjustable from 1 sec to 10 min
- IP67-rated thermoplastic polyester housing, 32 x 101mm
- 32 x 101mm round casing with 360° rotatable head
- Sensor mute input for temporary disabling of detection
Specifications
IP Rating | IP67 |
Mounting Type | Non-Flush |
Poles | SPDT |
Series | VC11RT |
Voltage Rating | 24V AC/DC |
Package Dimensions (L x W x H) | 7.87 in x 11.42 in x 0.47 in |
Package Weight (Imperial) | 0.62 lbs |
Frequently Asked Questions
What is the sensing distance for this capacitive sensor?
The sensing distance is adjustable from 4 to 12 mm.
What type of output does the VC11RT92410M provide?
It provides a Relay SPDT output rated at 2 A/240 VAC.
What is the operating temperature range for this sensor?
The sensor can operate in temperatures ranging from -20º to +70ºC (-4º to +158ºF).
What is the supply voltage for the VC11RT92410M model?
This model operates on 24 VAC/DC with a frequency of 47-63 Hz.
What is the maximum power consumption of the sensor?
The maximum power consumption for this sensor is 1.5 W.
What is the IP rating for this capacitive sensor?
The sensor has a degree of protection of IP 67.
What is the hysteresis of the sensor at 7 mm sensing distance?
The hysteresis is 1.5 mm at a 7 mm sensing distance.
What is the operating frequency of the sensor?
The operating frequency of the sensor is 1 Hz.
What is the housing material of the VC11RT92410M sensor?
The housing material is Thermoplastic polyester.
