Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 3-phase soft starter for induction motors
- Operating voltage: 400V AC
- Rated current: 12A
- DIN rail mount for space-efficient installation
- 2-phase control with internal supply voltage
Specifications
Current Rating | 12 A |
Mounting Type | DIN Rail |
Mounting Type | DIN Rail Mount |
Poles | 3P |
Poles | 3-Phase |
Poles | 2-phase |
Series | RSE |
Voltage Rating | 400 VAC |
Voltage Rating | 400V AC |
Package Dimensions (L x W x H) | 4.04 in x 1.8 in x 3.23 in |
Package Weight (Imperial) | 0.60 lb |
PSR12-600-70
The softstarter PSR12-600-70 has a rated maximum operational current of 12 A with an operating voltage span from 208...600 V AC. The rated control voltage is between 100...240 V AC at 50/60 Hz. PSR features a two-phase control soft start and stop through a voltage ramp. It has built-in bypass for easy installation and energy saving. A RUN signal is available from a relay output in NO (normally open state). The start/stop ramp and time is easy to set by three potentiometers on the front. PSR is often used in combination with a manual motor starter (MMS) from ABB, so mechanical connection kits are available. Another popular option is Fieldbus communication, which can be enabled by an external adaptor and a Fieldbus plug. The PSR range is our most compact softstarters with basic functionality and values. They are suitable for small three-phase motors with nominal currents from 3...105 A and can manage up to 100 starts per hour. Common applications are, for example, pumps, fans, compressors, and conveyors.
RSE6012-B
The Carlo Gavazzi RSE6012-B is a 3-phase soft starter designed for induction motors. It operates at 600Vac with a rated current of 12Aac, making it suitable for medium-duty motor control applications. The device features a control voltage range of 24-110Vac/dc and 110-480Vac, ensuring compatibility with a wide range of control systems. Mounted on a DIN rail for easy installation, it provides smooth motor starting to reduce mechanical stress and electrical surges. Manufactured by Carlo Gavazzi, a leader in industrial automation components, this soft starter is ideal for applications requiring reliable and precise motor control.Frequently Asked Questions
What is the rated operational current for the RSE4012-B?
The rated operational current for the RSE4012-B is 12 AAC.
What is the rated operational voltage range for this controller?
The rated operational voltage is up to 400 VAC, 50/60 Hz.
What control voltage options are available for the RSE4012-B?
Control voltage options are 24-110 VAC/DC and 110-480 VAC, both with ±15% tolerance.
What is the minimum load current for the RSE4012-B?
The minimum load current for the RSE4012-B is 200 mAAC rms.
What is the operating temperature range for the RSE4012-B?
The operating temperature range is -20° to +50°C (-4° to +122°F).
What is the storage temperature range for the RSE4012-B?
The storage temperature range is -50° to +85°C (-58° to +185°F).
What is the maximum tightening torque for the screw terminals?
The maximum tightening torque for the screw terminals is 0.5 Nm.
What is the terminal capacity of the RSE4012-B?
The terminal capacity is 2 x 2.5 mm².
Does the RSE4012-B provide overload protection?
No, overload protection is not provided and must be installed separately.
What is the maximum number of soft startings per hour at 25°C?
The maximum number of soft startings per hour at 25°C is 19.
