Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 3-phase soft starter for induction motors up to 16A
- Operates at 220V with UL certification
- DIN rail mounting for easy panel integration
- Smooth acceleration/deceleration reduces mechanical stress
- Compact design for space-constrained applications
Specifications
Current Rating | 16 A |
Mounting Type | DIN |
Poles | 3 |
Voltage Rating | 220 V |
Package Dimensions (L x W x H) | 4.5 in x 5.3 in x 1.9 in |
Package Weight (Imperial) | 1.10 lb |
PSR16-600-70
The softstarter PSR16-600-70 has a rated maximum operational current of 16 A with an operating voltage span from 208...600 V AC. The rated control voltage is between 100...240 V AC at 50/60 Hz. PSR features a two-phase control soft start and stop through a voltage ramp. It has built-in bypass for easy installation and energy saving. A RUN signal is available from a relay output in NO (normally open state). The start/stop ramp and time is easy to set by three potentiometers on the front. PSR is often used in combination with a manual motor starter (MMS) from ABB, so mechanical connection kits are available. Another popular option is Fieldbus communication, which can be enabled by an external adaptor and a Fieldbus plug. The PSR range is our most compact softstarters with basic functionality and values. They are suitable for small three-phase motors with nominal currents from 3...105 A and can manage up to 100 starts per hour. Common applications are, for example, pumps, fans, compressors, and conveyors.
Frequently Asked Questions
What is the ramp-up time for the RSBT soft starter?
The RSBT soft starter has a short ramp-up time of less than 600 ms.
What types of protection are integrated into the RSBT soft starter?
The RSBT soft starter includes over-temperature, overcurrent, and locked rotor protection.
What is the operating voltage range for the RSBT22 model?
The RSBT22 model has a rated operational voltage of 220 VAC.
What is the operating voltage range for the RSBT40 model?
The RSBT40 model has a rated operational voltage of 400 VAC.
What is the operating voltage range for the RSBT48 model?
The RSBT48 model has a rated operational voltage range of 220 - 480 VAC.
What is the control voltage range for RSBT..EV.. models?
The control voltage range for RSBT..EV.. models is 110 – 400 VAC with a tolerance of +10%, -15%.
What is the control voltage range for RSBT..CV.. models?
The control voltage for RSBT..CV.. models is 24 VAC/DC with a tolerance of ±10%, and also 110 - 400 VAC with a tolerance of +10%, -15%.
What is the operating temperature range for RSBT..16EV.. models?
The operating temperature range for RSBT..16EV.. models is -20ºC to +60ºC (-4ºF to +140ºF).
What is the maximum number of starts per hour for the RSBT soft starter at 40°C?
The maximum number of starts per hour at 40°C for the RSBT soft starter is 12.
What is the minimum time between stop and start for the RSBT soft starter?
The minimum time between stop and start for the RSBT soft starter is 1 second.
