Contact for Pricing
Overview
- Class 1 visible red laser for reliable detection up to 100mm
- Background suppression (BGS) with adjustable 20-125mm sensing range
- IO-Link v1.1 (COM2) for advanced configuration and diagnostics
- Selectable outputs: PNP/NPN/Push-Pull, normally open/closed
- Durable plastic housing, IP67 rated
Specifications
Color | Red |
Connection Type | M8 4-pin connector |
IP Rating | IP67 |
Material | Plastic |
Mounting Type | Top Button |
Series | LD30CP |
Size | 100mm |
Package Dimensions (L x W x H) | 8.66 in x 8.66 in x 0.47 in |
Package Weight (Imperial) | 0.04 lbs |
Frequently Asked Questions
What is the IP rating of the LD30CPBR10BPM5IO?
The sensor has an IP67 rating, providing protection against dust and water ingress.
What communication protocol does this sensor use?
The sensor uses IO-Link v1.1 (COM2, 38.4k Baud) for communication and configuration.
What is the housing material?
The housing is made of durable ABS plastic.
What is the operating voltage range?
The sensor operates on 10 to 30 volts DC, including ripple.
What output types are supported?
The sensor supports PNP, NPN, and Push-Pull outputs, configurable as normally open or normally closed.
Does this sensor support dual detection modes?
Yes, it combines foreground suppression with diffuse reflective detection for enhanced accuracy.
What are the dimensions of the sensor?
The sensor dimensions are 10 x 20 x 30 millimeters.
Can the sensing distance be adjusted?
Yes, the sensing distance is adjustable from 20 to 125 millimeters via teach-button or IO-Link.
What is the response time of the sensor?
The response time is down to 0.5 milliseconds depending on settings.
What applications is this sensor suitable for?
It is ideal for detecting transparent or translucent objects like plastic bottles in packaging and quality control applications.
