Brad Harrison WR8U40E02C300 - Ultra-Lock® (M12) Back Panel Mount Receptacle, 8 Pole, Female, M16x1.5 Mounting Threads, 0.25mm² PVC Leads, Length 0.30m
Brad Harrison

WR8U40E02C300

Alternate Item Number: 1200845097

UPC: 883906778507

Documents & Media
Technical Drawing

Contact for Pricing

Minimum Qty: 20

Multiplier: 20

*Contact for lower quantities*

Overview

The Brad Harrison WR8U40E02C300 is an M12, 8-pole female receptacle designed for robust back panel mounting applications. This A-coded connector features the Ultra-Lock® feature, ensuring secure mating with standard threaded M12 and Ultra-Lock cordsets. Manufactured by Brad Harrison, a trusted name in industrial connectivity, this receptacle is built for reliability in demanding environments. The housing is constructed from durable nickel-plated brass, providing excellent corrosion resistance. Contacts are made of copper alloy with gold over nickel plating for superior conductivity and longevity. The receptacle utilizes Polyamide for contact carries and Viton® for O-rings, ensuring effective sealing and chemical resistance. This specific model, WR8U40E02C300, is configured for back panel mounting from inside the enclosure, utilizing M16x1.5 mounting threads for secure installation. It comes equipped with 0.25mm² PVC insulated wire leads, 0.30 meters in length, suitable for termination to terminal strips or PCB tails. The fully potted assembly provides IP67/68 protection, making it ideal for harsh industrial settings where dust and water ingress are concerns. It is rated for a maximum current of 2.0A per contact and a voltage of 30V AC / 36V DC. This M12 receptacle is IEC compliant and cCSAus certified for 4- to 5-pole versions, indicating its adherence to international safety and performance standards. The wire insulation is rated for 300V and 80°C, conforming to UL1061 standards. This product is an essential component for sensor and actuator connectivity in automation systems, providing a reliable interface for data and power transmission.
  • M12, 8-pole, A-Coding, Female Receptacle
  • Ultra-Lock® feature for secure mating
  • Back Panel Mount with M16x1.5 Mounting Threads
  • 0.30m PVC Leads (0.25mm² wire size)
  • IP67/68 Protection for Harsh Environments

Specifications

_Orientation
Straight
Amperage Rating
2 A
Conductor Range
24
Conductor Range, Maximum
24
Conductor Range, Minimum
24
Connection
Internal Thread
Environmental Conditions
IP69K
NEMA Rating
6
Size
0.30m
Temperature Rating, Maximum
194 F
Temperature Rating, Maximum
90 C
Temperature Rating, Minimum
-13 F
Temperature Rating, Minimum
-25 C
Type
Single Ended (pigtail)
Voltage Rating
30V AC / 36V DC

Similar Products

WR8U46E02C300

Connection: External Thread

Material: PVC

Size: M16x1.5

WRCU40E01C300

Conductor Range: 26

Voltage Rating: 30V AC/DC

Amperage Rating: 1.5 A

WR8U40000

Type: PCB Mount

Conductor Range: None

Conductor Range, Maximum: None

WRCU46E01C300

Conductor Range: 26

Amperage Rating: 1.5 A

Voltage Rating: 30V AC/DC

WRCU20E01C300

Amperage Rating: 1.5 A

Conductor Range: 26

Voltage Rating: 30V AC/DC

WR8U46000

Conductor Range: None

Type: PCB Mount

Conductor Range, Maximum: None
