Contact for Pricing
Overview
- Enables failsafe, bi-directional data exchange in ModuleBus systems
- Supports IEC 25mm² (35mm² single slot >63A) and UL/CSA AWG18-4 cable connections
- Features shock-protected cylinder-lift and cage terminals for >63A currents
- Tool-less bottom withdrawal (except 125A models); 35mm DIN rail mounting
- Torque specs: 2.8 Nm IEC (3 Nm for 125A), 25 in-lbs UL/CSA (≤63A)
Specifications
CE mark | Yes |
Connection Type | Cylinder-lift terminals (top/bottom), cage terminals for >63A; IEC 25mm² (35mm² single slot for >63A) and UL/CSA AWG18-4 cable connections; IEC 10mm² (not for 80-100A) and UL/CSA AWG18-8 busbar connections |
Connection Type | Cylinder-lift terminals (shock protected) and cage terminals |
Corrosion protection | ISA-S71.04: G3 |
Current Rating | >63 A |
Depth | 25 mm |
Electrical safety | IEC 61131-2, UL 61010-1, UL 61010-2-201 |
EMC | EN 61000-6-4 and EN 61000-6-2 |
Equipment class | Class I according to IEC 61140; (earth protected) |
Hazardous Location | C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2 |
Height | 109 mm |
Marine certification | ABS, BV, DNV, LR |
Mechanical operating conditions | IEC 61131-2 |
Mechanics | S800 |
Mounting Type | 35mm DIN rail mount (any position) via fast clip |
Mounting Type | 35mm DIN rail via fast clip; any position supported |
Overvoltage categories | IEC/EN 60664-1 |
Poles | 2P |
Pollution degree | Degree 2, IEC 60664-1 |
Protection class | IP20 according to IEC 60529 |
RoHS compliance | EU RoHS, UAE RoHS, CN RoHS |
Series | TB806 |
Size | 85mm (H) x 69mm (D) x 35mm (W) for 2P |
Size | 85mm(H) x 69mm(D) x 35mm(W) |
Temperature, Operating | 0 to +55C (Storage -25 to +70C), RH=5 to 95% no condensation, IEC/EN 61131-2 |
WEEE compliance | DIRECTIVE/2012/19/EU |
Weight | 46 g |
Width | 22 mm |
Frequently Asked Questions
What cable sizes does the TB806 support?
The TB806 supports IEC 25mm² (35mm² single slot >63A) and UL/CSA AWG18-4 cable connections.
How is the TB806 mounted?
The TB806 is designed for 35mm DIN rail mounting in any position.
What are the torque specifications for the TB806?
Torque specifications are 2.8 Nm IEC (3 Nm for 125A models) and 25 in-lbs UL/CSA for ≤63A models.
Does the TB806 support tool-less installation?
Yes, the TB806 includes tool-less bottom withdrawal (except for 125A models).
What is the manufacturer of the TB806?
The TB806 is manufactured by ABB Process Automation.
