ABB - Installation Products XT13P - Cross Tap Clamp, Tin Plated, Conductor Range Main 4/0 - 1 Stranded 3/0 - 1 ACSR TAP 4/0 - 1 Stranded 3/0 - 1 ACSR.
ABB - Installation Products

XT13P

UPC: 783786400386

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 90

Multiplier: 90

*Contact for lower quantities*

Overview

The ABB XT13P Cross Tap Clamp is a tin-plated copper alloy clamp designed for secure connections between main and tap conductors in industrial and utility applications. This clamp accommodates a main conductor range of 4/0 to 1 AWG stranded and 3/0 to 1 AWG ACSR, with tap conductor compatibility matching the same ranges. The tin plating provides corrosion resistance, ensuring long-term reliability in harsh environments. The XT13P is part of ABB’s Installation Products line, known for durable, compliant electrical components. Typical applications include power distribution panels, substations, and renewable energy systems where parallel conductor tapping is required. The clamp’s design allows for efficient installation without specialized tools, reducing labor time. Compliance with industry standards ensures safe operation in both indoor and outdoor settings. For projects requiring reliable secondary connections, the XT13P delivers consistent performance with minimal maintenance.
  • Tin-plated copper alloy for corrosion resistance
  • Main conductor range: 4/0 to 1 AWG stranded
  • Tap conductor range: 4/0 to 1 AWG stranded, 3/0 to 1 AWG ACSR
  • Designed for parallel tapping in power distribution
  • Compatible with ABB Installation Products line

Specifications

Application
Multi-purpose Connector
Bolt Size
3/8 in
Connection
Mechanical
Enclosure
None
Environmental Conditions
All Seasons / Conditions
Finish
Tinned
Insulation
None
Material
Casting of Copper Alloy, Bolts of Silicon Bronze
Number of Conductors
2
Number Of Mounting Holes
None
Special Features
Design allows for free wrench rotation which speeds installation
Type
Mechanical Connector
Voltage Rating
35 kV
Package Dimensions (L x W x H)
6.5 IN x 5 IN x 3.37 IN
Package Dimensions (L x W x H)
16.51 cm x 12.7 cm x 8.5598 cm
Package Weight (Imperial)
0.7300 L
Package Weight (Metric)
0.3310 kg
Two-hole, copper, single barrel, straight tongue lug, #4 SOL - 500 kcmil, 3/8 (9.5mm) stud hole.

PNL-500-2-3

Two-hole, copper, single barrel, straight tongue lug, #4 SOL - 500 kcmil, 3/8 (9.5mm) stud hole.
Copper Type XT - Clamp for Tee-Tap, Cross, Parallel and End-to-End for Wire Range Main: 1 Stranded - 4/0 Stranded Tap: 1 - 4/0 Stranded, Bolt Size 3/8

XT13

Copper Type XT - Clamp for Tee-Tap, Cross, Parallel and End-to-End for Wire Range Main: 1 Stranded - 4/0 Stranded Tap: 1 - 4/0 Stranded, Bolt Size 3/8
U-Type Die 500Cu

BTP350-S

U-Type Die 500Cu
AF26-38 STAR DELTA PUSHIN CONNECT SET

BEY38-4KF

AF26-38 STAR DELTA PUSHIN CONNECT SET
Copper Type XT - Clamp for Tee-Tap, Cross, Parallel and End-to-End for Wire Range Main: 250 - 500 kcmil Tap: 1 - 4/0 Stranded, Bolt Size 3/8

XT22

Copper Type XT - Clamp for Tee-Tap, Cross, Parallel and End-to-End for Wire Range Main: 250 - 500 kcmil Tap: 1 - 4/0 Stranded, Bolt Size 3/8
Copper Type XT - Clamp for Tee-Tap, Cross, Parallel and End-to-End for Wire Range Main: 250 - 500 kcmil Tap: 6 Solid - 2 Stranded, Bolt Size 3/8

XT21

Copper Type XT - Clamp for Tee-Tap, Cross, Parallel and End-to-End for Wire Range Main: 250 - 500 kcmil Tap: 6 Solid - 2 Stranded, Bolt Size 3/8
Copper Type XT - Clamp for Tee-Tap, Cross, Parallel and End-to-End for Wire Range Main: 250 - 500 kcmil Tap: 250 - 500 kcmil, Bolt Size 3/8

XT23

Copper Type XT - Clamp for Tee-Tap, Cross, Parallel and End-to-End for Wire Range Main: 250 - 500 kcmil Tap: 250 - 500 kcmil, Bolt Size 3/8
Copper Type XT - Clamp for Tee-Tap, Cross, Parallel and End-to-End for Wire Range Main: 500 - 1000 kcmil Tap: 250 - 500 kcmil, Bolt Size 3/8

XT33

Copper Type XT - Clamp for Tee-Tap, Cross, Parallel and End-to-End for Wire Range Main: 500 - 1000 kcmil Tap: 250 - 500 kcmil, Bolt Size 3/8

Frequently Asked Questions

What conductor sizes does the XT13P support?

The XT13P supports main conductors from 4/0 to 1 AWG stranded and tap conductors from 4/0 to 1 AWG stranded or 3/0 to 1 AWG ACSR.

What material is the XT13P made of?

The XT13P is made of a copper alloy with a tin plating for enhanced corrosion resistance.

Is the XT13P suitable for outdoor use?

The tin plating on the XT13P provides corrosion resistance, making it suitable for outdoor and industrial environments.

Does the XT13P require special tools for installation?

No special tools are required for installation; a standard screwdriver is sufficient for securing the clamp.
