UPC: 783786051564
Documents & Media
Contact for Pricing
Overview
- Aluminum compression H-tap connector for overhead distribution systems
- Tin-plated copper stirrup with Contax filler for corrosion resistance
- Supports wire ranges: 2-6 AWG ASCR, 1-strand to 6-solid AWG
- Square stirrup (#2 solid copper) measures 4.5 x 3.75 inches
- Designed for reliable, long-term electrical connections
Specifications
Application | Protect Main Conductors from Arcing Damage |
Connection | Compression |
Housing Material | Aluminum with Tin Plated Copper Bails |
Insulation | None |
Size | 4-1/2 X 3-3/4 inches Tall |
Special Features | Guard Main Conductors Against Arcs - Perfect for when Hot Line Taps are Installed. Utilize Standard Wide Range Connectors and Plated Copper Bails for High Conductivity and Corrosion Resistance |
Type | Compression Connector with Stirrup |
Wire Size | #2 to #6 ACSR , #1 STR AWG , #6 SOL |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 0.3800 L |
Package Weight (Metric) | 0.1720 kg |
WRQ154
Aluminum Compression H-Tap Connector with Tin Plated Copper Stirrup, Contax Filled, Wire Range: 2-6 ASCR, 1 Stranded -6 Solid AWG, Stirrup #4 Solid Copper, square shaped, 1 H-Tap Connector on Stirrup. 4-1/2 inch x 3-3/4 inch.
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
TR66
Aluminum 6 inch Service Entrance Compression Splice for Wire Range 1/0 ASCR, 1/0 Stranded, Dies: 5/8, TU, 8A, 243, 52. Pre-filled with Oxide Inhibitor with Yellow Caps. For Aluminum Conductors
WR359
Aluminum Wide Range H-Type Compression Connector Main: 4/0 - 3/0 ACSR, 4/0 - 3/0 Str., Tap: 4-6 ACSR, 3-6 Str., 2-6 Sol., Die: D, D3. 1-7/8 inch.
WR399
Aluminum Wide Range H-Type Compression Connector, Main: 4/0 - 3/0 ACSR, 4/0 - 3/0 Str. Tap: 2/0 - 1 ACSR, 2/0 - 1/0 Str. 3/0 - 2/0 Sol. 2-3/16 inch
CS65
Aluminum 2 Inch Service Entrance Compression Splice for Wire Range - End A: 4 6/1,7/1 ASCR, 3-4 Stranded, 2 Solid, Orange, End B: 10 Stranded, 8 Solid, Brown, Die: 5/8. For AL-AL or AL-CU Conductors.
CS67
Aluminum 2 Inch Service Entrance Compression Splice for Wire Range - End A: 4 6/1,7/1 ASCR, 3-4 Stranded, 2 Solid, Orange, End B: 6 6/1 ASCR, 6 Stranded, 4 Solid, Blue, Die: 5/8. For AL-AL or AL-CU Conductors.Frequently Asked Questions
What are the dimensions of the WRQ152 connector?
The WRQ152 measures 4.5 inches by 3.75 inches.
What wire sizes does the WRQ152 support?
The WRQ152 supports wire ranges from 2-6 AWG ASCR and 1-strand to 6-solid AWG.
Is the WRQ152 suitable for aluminum conductors?
Yes, the WRQ152 is designed for use with aluminum conductors in the specified wire range.
What is the stirrup material in the WRQ152?
The stirrup is made of #2 solid copper with a tin plating.
What is Contax filler used for in the WRQ152?
Contax filler is used to prevent corrosion and ensure long-term conductivity.
