ABB Installation Products WP39JAR100 Marrette WP39 weatherproof wire connector, black, wire range #20 - #8, jar of 100 units
UPC: 708917415596
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Weatherproof design with IP68 rating for outdoor/damp environments
- Accommodates wire sizes #20 to #8 AWG (copper/aluminum)
- Twist-on installation for quick, tool-free splicing
- UL-listed and CSA-certified for wet locations (NEC Article 314.16)
- Bulk packaging: 100 units per jar for cost-effective procurement
Specifications
Color | Blue/Red |
Conductor Range | #20 - #10 AWG |
Material | Polypropylene |
Mounting | Twist-On |
Temperature Rating, Maximum | 105 F |
Temperature Rating, Maximum | 221 C |
Temperature Rating, Minimum | 105 F |
Temperature Rating, Minimum | 221 C |
Type | Weatherproof Wire Connector |
Voltage Rating | 600 V |
Wire Type | Copper solid/stranded |
Package Dimensions (L x W x H) | 1.86 IN x 1.04 IN x 0.001 IN |
Package Dimensions (L x W x H) | 4.7244 cm x 2.6416 cm x 0.0025 cm |
Package Weight (Imperial) | 0.0200 L |
Package Weight (Metric) | 0.0091 kg |
TM-TR-100P
TERMINATOR Tan/Red Premium Wire Connectors with Steel Springs, Rated for copper wire in 18-8 AWG Wire Range. Dual color coding means one premium wire connector does the job of two standard connectors in most applications.
WC-G-B
The Easy-Twist WC-G-B 1,000 Bag of Standard-Style Grey Wire Connectors are designed for use on copper wires in the 22-14 AWG size range. They’re made of flame-retardant thermoplastic rated for a maximum temperature of 105˚ Celsius (221˚ Fahrenheit). The quick-grip square spring design grips in fewer twists and can dead-end a single wire, while the ergonomic ribbed texture makes them easy to twist. Their compact design is useful for applications in tight areas or anywhere else you need to connect wires.
WC-R-D
The Easy-Twist WC-R-D Bulk 25,000 Fibre Drum of Standard-Style Red Wire Connectors are designed for use on copper wires in the 22-10 AWG size range. They’re made of flame-retardant thermoplastic rated for a maximum temperature of 105˚ Celsius (221˚ Fahrenheit). The quick-grip square spring design grips in fewer twists and can dead-end a single wire, while the ergonomic ribbed texture makes them easy to twist. Their compact design is useful for applications in tight areas or anywhere else you need to connect wires.
WC-R-B
The Easy-Twist WC-R-B 500-Count Bag of Standard-Style Red Wire Connectors are designed for use on copper wires in the 22-10 AWG size range. They’re made of flame-retardant thermoplastic rated for a maximum temperature of 105˚ Celsius (221˚ Fahrenheit). The quick-grip square spring design grips in fewer twists and can dead-end a single wire, while the ergonomic ribbed texture makes them easy to twist. Their compact design is useful for applications in tight areas or anywhere else you need to connect wires.
WC-Y-D
The Easy-Twist WC-Y-D Bulk 35,000-Count Fibre Drum of Standard-Style Yellow Wire Connectors are designed for use on copper wires in the 22-8 AWG size range. They’re made of flame-retardant thermoplastic rated for a maximum temperature of 105˚ Celsius (221˚ Fahrenheit). The quick-grip square spring design grips in fewer twists and can dead-end a single wire, while the ergonomic ribbed texture makes them easy to twist. Their compact design is useful for applications in tight areas or anywhere else you need to connect wires.Frequently Asked Questions
How many connectors are included in one jar?
Each jar contains 100 units of the WP39 weatherproof wire connector.
What wire sizes does the WP39 connector support?
The WP39 accommodates wire sizes ranging from #20 to #8 AWG, including both copper and aluminum conductors.
Is the WP39 connector suitable for outdoor use?
Yes, the WP39 is IP68-rated for protection against moisture, dust, and corrosion, making it ideal for outdoor and damp environments.
Does the WP39 require tools for installation?
No, the WP39 features a twist-on design that allows for tool-free installation.
What certifications does the WP39 have?
The WP39 is UL-listed and CSA-certified for use in wet locations per NEC Article 314.16.
