ABB Installation Products VBRACKET40KA Wall Mounting Bracket, Mechanical Support, Stainless Steel, 40kA. Includes (6) Cap…
UPC: 783786804078
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Durable stainless steel construction for longevity
- Rated for 40kA to handle high fault currents
- Complete mounting kit with all necessary hardware included
- Designed for secure wall mounting of electrical equipment
- Manufactured by ABB - Installation Products
Specifications
Current Rating | 40 kA |
Material | Stainless Steel |
Mounting Type | Wall Mounting |
Type | Wall Mounting Bracket |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 1.0000 L |
Package Weight (Metric) | 0.4540 kg |
U510SS
Bracket, Z Shape, Total Length 3 Inches, Top Length 1 Inch, Rise 1 Inch, Width 1-1/2 Inch, Set Screw 1/2 Inch x 1-1/2 Inch, Stainless Steel, For use with A-1200 and A-1400 Channel
750J2-6
Bracket for Junction, 2 Point, 600 Amp, 35kV, Hardware Pacjage consists of Brackets and Straps Only
1601US-1
Hold Down Bracket Prepack. 13 Gage 304 Stainless Steel. 3.124 x 2.675 inch x Widest Width at Pad .625 inch. 2.5 inch between Holes. 0.375 inch Diameter Holes on each Side of Bracket.
PWBTSBEZ-L
Wire Basket Trapeze Support Bracket can be used to support baskets ranging from 4" wide through 12" wide from threaded rod. It comes in an electro zinc plated finish. This kit comes packaged in quantities of 50 pieces. Threaded rod, washers, and nuts not included.
SBD
1-1/2" Standoff Bracket for Decking (Complies NEC® Sec. 300.4(E)), 1/4" Mounting Holes, Pre-Galvanized Steel
CA3HLS4
A 3 hole cross corner angle made from 304 stainless steel. It measures 4-1/8 in in height and 1-5/8 in in length and width, with a thickness of 1/4 in. It has 3 holes.Frequently Asked Questions
What is the current rating of the VBRACKET40KA?
The ABB VBRACKET40KA is rated for 40kA, indicating its capacity to handle significant fault currents.
What material is the VBRACKET40KA made from?
The VBRACKET40KA is constructed from durable stainless steel, ensuring longevity and resistance to environmental factors.
What hardware is included with the VBRACKET40KA?
The VBRACKET40KA includes (6) Cap Plugs, (6) Hex Nuts 1/2-13, (6) Lock Washers, (12) Flat Washers, (6) Hex Head Cap Screws, a Left Foot, a Right Foot, and an Instruction Sheet IS-1184.
What is the purpose of the VBRACKET40KA?
The VBRACKET40KA serves as a mechanical support for wall mounting applications, designed to handle high current ratings.
Who is the manufacturer of the VBRACKET40KA?
The VBRACKET40KA is manufactured by ABB under their Installation Products division.
How to Install the ABB VBRACKET40KA Wall Mounting Bracket
Step-by-step installation guide for the VBRACKET40KA.
Estimated time: 30m
Tools needed:
Wrench, Drill, Level
Supplies needed:
Wall anchors (if required by wall type), Appropriate fasteners for wall mounting
- Prepare the Mounting Location
Identify the desired wall location for mounting. Ensure the wall is structurally sound and capable of supporting the intended load. Use a level to mark the precise mounting points.
- Attach Feet to Bracket
Secure the Left Foot and Right Foot to the main Wall Bracket using the provided Hex Head Cap Screws, Flat Washers, Lock Washers, and Hex Nuts. Ensure these are tightened securely.
- Mount Bracket to Wall
Align the assembled bracket with the marked mounting points on the wall. If necessary, drill pilot holes and install appropriate wall anchors. Use the provided Hex Head Cap Screws, Flat Washers, and Hex Nuts to firmly attach the bracket to the wall. Ensure the bracket is level and securely fastened.
- Install Cap Plugs
Insert the Cap Plugs into any exposed threaded holes on the bracket for a clean finish and protection.
