ABB - Installation Products UGG 88 - Aluminum 2-3/4 inch Service Entrance Compression Splice for Wire Range, End A: 8 Stranded, 6 Solid, Green, End B: 8 Stranded, 6 Solid, Green, Die: 5/8. Aluminum to Copper Conductors.

ABB Installation Products UGG 88 Aluminum 2-3/4 inch Service Entrance Compression Splice for Wire Range, End A: 8…

UPC: 783786754663

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 1000

Multiplier: 1000

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

This ABB Installation Products UGG 88 is a 2-3/4 inch aluminum service entrance compression splice designed for reliable conductor connections. It facilitates the joining of aluminum to copper conductors, a common requirement in electrical infrastructure. The splice is engineered to accommodate specific wire ranges on both ends. End A accepts 8 AWG stranded and 6 AWG solid conductors, while End B also accommodates 8 AWG stranded and 6 AWG solid conductors. Both ends are marked with a green color code for easy identification and proper application. The required die for installation is 5/8 inch. This component is crucial for ensuring secure and efficient electrical pathways in service entrance applications. Its construction from aluminum ensures good conductivity and corrosion resistance for long-term performance. The specific wire size compatibility ensures a precise fit, minimizing resistance and potential failure points. The UGG 88 is a direct solution for connecting conductors of varying types and sizes within the specified ranges, meeting the practical needs of electrical installations. Manufacturer: ABB - Installation Products. SKU: UGG 88. UNSPSC Code: 39121449.
  • 2-3/4 inch aluminum service entrance compression splice
  • Connects aluminum to copper conductors
  • End A: 8 AWG Stranded, 6 AWG Solid
  • End B: 8 AWG Stranded, 6 AWG Solid
  • Green color-coded for identification, requires 5/8" die

Specifications

Application
For Standard Comductors
Color
Green
Color
Green/Green
Conductor Range
Side A: #8 STR , #6 SOL Side B: #8 STR , #6 SOL
Connection
Compression
Connection Type
Compression Splice
Insulation
Insulated
Material
Aluminum
Number Of Conductors
2
Size
2-3/4 inch
Size
2-25/32 inches long
Special Features
Prefilled with Oxide Inhibitor and topped with color-coded end caps. Prevents oxidation and keeps out moisture. Solid Center Stops. Easy cable insertion. All splices are marked with installation die codes and compression locations for easy identificaton and installation. Tough Stabilized Nylon Sleeves Resist Installing-tool Pressure and Provide Reliable 600V insulaton
Standard
ANSI C119.4
Type
Compression Splice Service Entrance Insulated
Package Dimensions (L x W x H)
15.62 IN x 4 IN x 4.5 IN
Package Dimensions (L x W x H)
39.6748 cm x 10.16 cm x 11.43 cm
Package Weight (Imperial)
0.0400 L
Package Weight (Metric)
0.0180 kg
