Contact for Pricing
Minimum Qty: 120
Multiplier: 120
*Contact for lower quantities*
Overview
- 3-inch width x 1-inch height dimensions
- Narrow slot design for secure cable retention
- Constructed from intrinsic blue PVC material
- Ideal for electrical panels, control cabinets, and machinery
- Provides organized and protected wire routing
Specifications
Adhesive | False |
Adhesive | No |
Adhesive Backed | No |
Color | Blue |
Color | Intrinsic Blue |
Depth | 1 in |
Depth | 25.4 mm |
Length | 6 ft , 1.83 m |
Length | 72 in |
Length | 1830 mm |
Material | PVC |
Material | Intrinsic Blue PVC |
Material Quality | Polyvinyl Chloride (PVC) |
Series | TYD |
Size | 3 Inches x 1 Inch |
Slot Style | Narrow |
Type | Narrow Slot Duct |
Width | 3 in |
Width | 76.2 mm |
Package Dimensions (L x W x H) | 72 IN x 3 IN x 1 IN |
Package Dimensions (L x W x H) | 182.88 cm x 7.62 cm x 2.54 cm |
Package Weight (Imperial) | 0.180 L |
Package Weight (Metric) | 0.082 kg |
Frequently Asked Questions
What is the temperature rating of the product?
The temperature rating is -40°F to 140°F (-40°C to 60°C).
What materials are used in this product?
The product is made from West Lake Chemical 5055 PVC with a 100% regrind level.
What are the dimensions of the wiring duct?
Dimensions vary by catalog number; for example, TYD3X1NP*6 is 3.250 inches wide and 1.055 inches high.
What is the flammability rating?
The flammability rating is UL94V-0.
What is the retention feature of the cover?
The cover has a flush mount design and includes a wire retention bump.
What types of cables can be used with this product?
The product supports various cable types including THHN and UTP/CM for data cables.
Are there specific installation requirements?
The product features North American and DIN style mounting holes for installation.
What is the wire fill based on?
Wire fill is based on 50% fill of duct area.
What safety precautions should be taken?
Always follow local electrical codes and safety standards during installation.
What is the maximum operating voltage?
The document does not specify a maximum operating voltage for the product.
