Contact for Pricing
Minimum Qty: 120
Multiplier: 120
*Contact for lower quantities*
Overview
- 2x2 inch narrow-slot wiring duct for cable management
- Intrinsic blue PVC material with impact, chemical, and UV resistance
- Compatible with standard DIN rail mounting systems
- Secure cable retention with easy installation and access
- Ideal for control panels, machinery, and electrical enclosures
Specifications
Adhesive | No |
Adhesive | False |
Adhesive Backed | No |
Color | Blue |
Color | Intrinsic Blue |
Depth | 2 in |
Depth | 50.8 mm |
Length | 6 ft , 1.83 m |
Length | 72 in |
Length | 1830 mm |
Material | PVC |
Material Quality | Polyvinyl Chloride (PVC) |
Mounting Type | DIN Rail |
Series | TYD |
Size | 2" x 2" |
Size | 2x2 Inch |
Slot Style | Narrow |
Type | Narrow Slot Duct |
Width | 2 in |
Width | 50.8 mm |
Package Dimensions (L x W x H) | 72 IN x 2 IN x 2 IN |
Package Dimensions (L x W x H) | 182.88 cm x 5.08 cm x 5.08 cm |
Package Weight (Imperial) | 0.280 L |
Package Weight (Metric) | 0.127 kg |
Frequently Asked Questions
What is the temperature rating of the product?
The temperature rating is -40°F to 140°F (-40°C to 60°C).
What materials are used in the product?
The product is made from West Lake Chemical 5055 PVC with a 100% regrind level.
What is the flammability rating?
The flammability rating is UL94V-0.
What types of mounting holes are included?
The product features North American and DIN style mounting holes.
What are the dimensions of the product?
Dimensions vary by catalog number; for example, TYD2X2NPI6 measures 2.034 inches by 1.249 inches.
What is the wire fill capacity?
Wire fill is based on 50% fill of duct area, with specific capacities for various wire gauges.
Is the product compatible with specific wire types?
Yes, it is compatible with various wire types, including THHN and UTP/CM cables.
How should the product be installed?
Installation requires flush mounting with side walls, ensuring the cover mounts flush.
What is the retention feature of the cover?
The cover includes a retention bump for secure fitting.
What safety precautions should be taken?
Ensure proper installation and adhere to the temperature and flammability ratings to maintain safety.
