ABB - Installation Products TSC 16-8585 - Nema Transformer Spade Adapter, Aluminum Pad with (16) .562 Diameter Holes - 4 Rows of 4 Holes, 7.00 Long X 8.00 High X .750 Wide. 1.75 inch Spacing.

ABB Installation Products TSC 16-8585 Nema Transformer Spade Adapter, Aluminum Pad with (16) .562 Diameter Holes - 4 Rows of 4…

UPC: 783786754243

Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB Installation Products Nema Transformer Spade Adapter (SKU: TSC 16-8585) is a robust aluminum pad designed for secure electrical connections. This adapter features a grid of sixteen .562 diameter holes, arranged in four rows of four, providing ample termination points for transformer leads or other conductors. The hole spacing is set at 1.75 inches, facilitating organized and reliable wiring. The pad measures 7.00 inches in length, 8.00 inches in height, and 0.750 inches in width, offering a substantial surface area for mounting and connection. Constructed from durable aluminum, this adapter ensures conductivity and resistance to environmental factors common in industrial settings. Its Nema classification indicates adherence to specific industry standards for electrical enclosures and components. This spade adapter is suitable for use in transformer installations, power distribution systems, and other applications requiring secure, multi-point electrical connections. The UNSPSC code 39121443 categorizes this product under electrical connectors and accessories. ABB, a recognized leader in power and automation technologies, manufactures this component to support reliable electrical infrastructure.
  • Aluminum pad construction for conductivity and durability
  • Sixteen .562 diameter holes for secure conductor termination
  • Arranged in 4 rows of 4 holes with 1.75 inch spacing
  • Dimensions: 7.00" Long x 8.00" High x 0.750" Wide
  • Manufacturer: ABB - Installation Products

Specifications

Connection
Mechanical
Finish
Bare
Height
8 in
Height
203.2 mm
Insulation
False
Material
Aluminum
Nema Rating
NEMA Transformer Spade Adapter
Series
TSC
Size
7.00 Long X 8.00 High X .750 Wide
Type
NEMA Transformer Spade Adapter
Width
.75 in
Width
19.05 mm
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
1.0000 L
Package Weight (Metric)
0.4540 kg
